Placas Controladoras / SAS/SATA / 08 Canais / 4XC0G88850

Placas Controladoras / SAS/SATA

4XC0G88850 Controladora Lenovo SAS SATA 520i

8 Canais 12Gb/s 2 X SFF-8643, PCI Express 3.0 X8 Low profile

4XC0G88850 Controladora Lenovo SAS SATA 520i

*As imagens podem ser ilustrativas

envio de 30 a 60 dias uteis

R$ 3.981,00

à vista no Pix ou Boleto

ou R$ 4.189,81 em 1x no cartão (via site)

ou R$ 4.422,58 no cartão em até 10x sem juros (apenas na loja física)

R$ 3.981,00

à vista no Pix ou Boleto

R$ 4.189,81
em 1x no cartão (via site)

R$ 4.422,58 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

84733049

R$ 3.981,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 84733049

Cotação PJ mais de uma unidade

Indicar 4XC0G88850

4XC0G88850 Controladora Lenovo SAS SATA 520i
8 Canais 12Gb/s 2 X SFF-8643, PCI Express 3.0 X8 Low profile

Condição de 4XC0G88850: Novo em embalagem comercial

Garantia de 4XC0G88850: 12 meses direto com a Net Computadores

The ThinkServer RAID 520i Adapter is an entry-level 12 Gb SAS/SATA internal RAID adapter that offers a cost-effective RAID solution for small to medium business customers.

This product guide provides essential presales information to understand the RAID 520i adapter and it key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the RAID 520i adapter and consider its use in IT solutions.

Technical specifications

The ThinkServer RAID 520i adapter has the following specifications:

LSI SAS3008 12 Gbps I/O controller.

PCIe low profile adapter, based on the LSI 9340-8i adapter

8 internal SAS/SATA ports (supporting 12, 6, or 3 Gbps SAS speeds and 6 or 3 Gbps SATA speeds)

Two internal x4 HD Mini-SAS connectors (SFF-8643)

PCI Express 3.0 x8 host interface.

Support for SAS and SATA HDDs and SSDs.

Support for intermixing SAS and SATA HDDs and SSDs. Mixing SAS and SATA drives in the same array is not supported. Mixing of HDDs and SSDs in the same array is not supported.

Support for intermixing of 12 Gbps and 6 Gbps drives.

Operates in integrated MegaRAID (iMR) mode

Support for RAID 0, 1, 10 standard; optional support for cacheless RAID 5 and 50 with the addition of a hardware key.

Supports JBOD mode

Support for up to 64 virtual disks, up to 128 arrays, up to 16 virtual disks per array

Support for logical drive sizes greater than 2 TB.

Stripe size: 64 KB fixed

Supports 512e and 4K sector formatted drives

Supports T-10 Protection Information (PI) data protection

Compliant with Disk Data Format (DDF) configuration on disk (CoD).

S.M.A.R.T. support.

LSI MegaRAID management suite: MegaRAID Storage Manager, StorCLI command-line interface, and HII UEFI Human Interface Infrastructure

Maiores detalhes de 4XC0G88850 no site do fabricante:
https://lenovopress.com/lp0555.pdf

Tags de 4XC0G88850: 4XC0G88850, Lenovo 4XC0G88850, Controladora Lenovo 4XC0G88850, Controladora 8 Portas, Controladora 8 Portas Lenovo, Controladora 8 Canais Lenovo, 8 Canais SAS SATA, Lenovo

4XC0G88850 Controladora Lenovo SAS SATA 520i 8 Canais 12Gb/s 2 X SFF-8643, PCI Express 3.0 X8 Low profile

Condição de 4XC0G88850:
Novo em embalagem comercial

Garantia de 4XC0G88850:
12 meses direto com a Net Computadores

The ThinkServer RAID 520i Adapter is an entry-level 12 Gb SAS/SATA internal RAID adapter that offers a cost-effective RAID solution for small to medium business customers.

Technical specifications

The ThinkServer RAID 520i adapter has the following specifications:

LSI SAS3008 12 Gbps I/O controller.

PCIe low profile adapter, based on the LSI 9340-8i adapter

8 internal SAS/SATA ports (supporting 12, 6, or 3 Gbps SAS speeds and 6 or 3 Gbps SATA speeds)

Two internal x4 HD Mini-SAS connectors (SFF-8643)

PCI Express 3.0 x8 host interface.

Support for SAS and SATA HDDs and SSDs.

Support for intermixing SAS and SATA HDDs and SSDs. Mixing SAS and SATA drives in the same array is not supported. Mixing of HDDs and SSDs in the same array is not supported.

Support for intermixing of 12 Gbps and 6 Gbps drives.

Operates in integrated MegaRAID (iMR) mode

Support for RAID 0, 1, 10 standard; optional support for cacheless RAID 5 and 50 with the addition of a hardware key.

Supports JBOD mode

Support for up to 64 virtual disks, up to 128 arrays, up to 16 virtual disks per array

Support for logical drive sizes greater than 2 TB.

Stripe size: 64 KB fixed

Supports 512e and 4K sector formatted drives

Supports T-10 Protection Information (PI) data protection

Compliant with Disk Data Format (DDF) configuration on disk (CoD).

S.M.A.R.T. support.

LSI MegaRAID management suite: MegaRAID Storage Manager, StorCLI command-line interface, and HII UEFI Human Interface Infrastructure
