ACS8016DAC-400 Vertiv Avocent ACS 8000 16 Port Rack 19

Name: ACS8016DAC-400 Vertiv Avocent ACS 8000 16 Port Rack 19
Brand: Vertiv Avocent
SKU: ACS8016DAC-400
Price: 39277.00 BRL
Availability: InStock

Serial Console Server 16 Port | Dual AC Power | 1GB DDR3 | Twisted Pair | 2x Optical Fiber

clique para ampliar

*As imagens podem ser ilustrativas

envio de 30 a 60 dias uteis

R$ 39.277,00

à vista no Pix ou Boleto

ou R$ 41.343,86 em 1x no cartão (via site)

ou R$ 43.640,74 no cartão em até 10x sem juros (apenas na loja física)

R$ 39.277,00

à vista no Pix ou Boleto

R$ 41.343,86
em 1x no cartão (via site)

R$ 43.640,74 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

85444200

R$ 39.277,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 85444200

Cotação PJ mais de uma unidade

Indicar ACS8016DAC-400

ACS8016DAC-400 Vertiv Avocent ACS 8000 16 Port Rack 19
Serial Console Server 16 Port | Dual AC Power | 1GB DDR3 | Twisted Pair | 2x Optical Fiber

Condição de ACS8016DAC-400: Novo em embalagem comercial

Garantia de ACS8016DAC-400: 12 meses direto com a Net Computadores

Remote MANAGEMENT: Avocent ACS8000 16-Port advanced terminal management Serial Console Server allows users to access and troubleshoot remote locations using automatic network failover to Cellular (and failback).
8 USB 2.0 Ports: support external devices, IoT products and IT equipment; Features digital input/ output sensor ports and 16 RS232 serial.
Automated PROVISIONING: Offers Fast, automated configuration with zero touch provisioning; compliant with data center access and security policies; powerful Dual-core ARM processor and 16GB of flash memory to support automation scripting.
Power DEVICE MANAGEMENT: Dual 1GB Ethernet port for network connectivity, failover, and secure in-band management for daily networking management. Comes with expanded support for Rack PDUs from Vertiv and 3rd-party along with Vertiv GXT4 UPS systems.
Environmental sensor port: connect to temperature, humidity, differential pressure, leak, and door pin sensors.

The Vertiv Avocent ACS8000 advanced serial console server series delivers secure in-band and out-of-band visibility and control to downstream equipment in enterprise data centers, as well as cloud and colocation facilities. This serial console system serves as a secure management gateway and single point of entry keeping you connected to critical IT equipment even in the event of partial or total data center outages. With serial access, environmental monitoring, and comprehensive activity logs for all connected devices, the Vertiv Avocent ACS8000 series provides secure equipment access and control across your data center.

In-band and out-of-band connectivity and control for connected devices.
Single IP address management, acting as an IoT gateway for connected sensors and digital inputs and outputs.
Single-point-of-entry security for all downstream equipment.
Auto-discovery and native command settings for monitoring and management of Vertiv and third-party equipment.
USB and environmental sensor ports for external devices and environmental monitoring.

Specifications

General
Depth	9.5 in
Device Type	Console server
Height	1.8 in
Height (Rack Units)	1U
Weight	7.5 lbs
Width	17.3 in

Communications
Supported Flash Memory Cards	SD Memory Card

Environmental Parameters
Humidity Range Operating	20 - 80% (non-condensing)
Max Operating Temperature	140 F
Min Operating Temperature	14 F

Expansion / Connectivity
Interfaces	16 x RS-232 - RJ-45 2 x 1000Base-T - RJ-45 1 x console - RJ-45 2 x - SFP (mini-GBIC) 8 x USB 2.0 - Type A 1 x sensor - RJ-45 4 x sensor

Miscellaneous
Compliant Standards	FCC Class A certified, UL, VCCI, cUL, EN 60950, ICES-003, CB, KCC, RCM, CU

Networking
Authentication Method	Kerberos, SecurID, Secure Shell (SSH), RADIUS, PAP, CHAP, X.509 certificates, TACACS , Secure Shell v.2 (SSH2), LDAP, Active Directory, Extensible Authentication Protocol (EAP), DSView
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Features	NAT support, Syslog support, packet filtering, IPv6 support, temperature sensor, SNMP trap, e-mail notification
Form Factor	External
Network / Transport Protocol	IPSec, NFS
Ports Qty	16
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, TFTP, SSH, CLI

Power
Installed Qty	2
Max Supported Qty	2
Power Consumption Operational	28 Watt
Power Device	Internal power supply
Power Redundancy	Yes
Voltage Required	AC 120/230 V (50/60 Hz)

Processor / Memory / Storage
Flash Memory	16 GB
Max Supported Qty	1
Processors Installed	1 x ARM Cortex-A9 MPCore
RAM	1 GB DDR3L SDRAM

Software / System Requirements
OS Provided	Linux

Vídeo de ACS8016DAC-400 Vertiv Avocent ACS 8000 16 Port Rack 19

Tags de ACS8016DAC-400: ACS8016DAC-400, ACS8016DAC400, ACS8016DAC-404, ACS8016DAC404, ACS6016DAC-G2, ACS6016DACG2, ACS 5016-001, ACS 5016001, Serial console, console serial, Vertiv Avocent

ACS8016DAC-400 Vertiv Avocent ACS 8000 16 Port Rack 19 Serial Console Server 16 Port | Dual AC Power | 1GB DDR3 | Twisted Pair | 2x Optical Fiber

Condição de ACS8016DAC-400:
Novo em embalagem comercial

Garantia de ACS8016DAC-400:
12 meses direto com a Net Computadores

Remote MANAGEMENT: Avocent ACS8000 16-Port advanced terminal management Serial Console Server allows users to access and troubleshoot remote locations using automatic network failover to Cellular (and failback).
8 USB 2.0 Ports: support external devices, IoT products and IT equipment; Features digital input/ output sensor ports and 16 RS232 serial.
Automated PROVISIONING: Offers Fast, automated configuration with zero touch provisioning; compliant with data center access and security policies; powerful Dual-core ARM processor and 16GB of flash memory to support automation scripting.
Power DEVICE MANAGEMENT: Dual 1GB Ethernet port for network connectivity, failover, and secure in-band management for daily networking management. Comes with expanded support for Rack PDUs from Vertiv and 3rd-party along with Vertiv GXT4 UPS systems.
Environmental sensor port: connect to temperature, humidity, differential pressure, leak, and door pin sensors.

In-band and out-of-band connectivity and control for connected devices.
Single IP address management, acting as an IoT gateway for connected sensors and digital inputs and outputs.
Single-point-of-entry security for all downstream equipment.
Auto-discovery and native command settings for monitoring and management of Vertiv and third-party equipment.
USB and environmental sensor ports for external devices and environmental monitoring.

Specifications

General
Depth	9.5 in
Device Type	Console server
Height	1.8 in
Height (Rack Units)	1U
Weight	7.5 lbs
Width	17.3 in

Communications
Supported Flash Memory Cards	SD Memory Card

Environmental Parameters
Humidity Range Operating	20 - 80% (non-condensing)
Max Operating Temperature	140 F
Min Operating Temperature	14 F

Expansion / Connectivity
Interfaces	16 x RS-232 - RJ-45 2 x 1000Base-T - RJ-45 1 x console - RJ-45 2 x - SFP (mini-GBIC) 8 x USB 2.0 - Type A 1 x sensor - RJ-45 4 x sensor

Miscellaneous
Compliant Standards	FCC Class A certified, UL, VCCI, cUL, EN 60950, ICES-003, CB, KCC, RCM, CU

Networking
Authentication Method	Kerberos, SecurID, Secure Shell (SSH), RADIUS, PAP, CHAP, X.509 certificates, TACACS , Secure Shell v.2 (SSH2), LDAP, Active Directory, Extensible Authentication Protocol (EAP), DSView
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Features	NAT support, Syslog support, packet filtering, IPv6 support, temperature sensor, SNMP trap, e-mail notification
Form Factor	External
Network / Transport Protocol	IPSec, NFS
Ports Qty	16
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, TFTP, SSH, CLI

Power
Installed Qty	2
Max Supported Qty	2
Power Consumption Operational	28 Watt
Power Device	Internal power supply
Power Redundancy	Yes
Voltage Required	AC 120/230 V (50/60 Hz)
