BGA-260 HDMI Transceiver
R$ 115,00
à vista no Pix ou Boleto
ou R$ 120,20 em 1x no cartão (via site)
ou R$ 126,88 no cartão em até 10x sem juros (apenas na loja física)
R$ 115,00
à vista no Pix ou Boleto
R$ 120,20
em 1x no cartão (via site)
R$ 126,88 no cartão
em até 10x sem juros
(apenas na loja física)
R$ 115,00
à vista no pix
Condição de ADV7626: Novo em embalagem comercial
Garantia de ADV7626: 7 dias troca. Sem garantia após soldado
Outros PNs para este item: ADV7626KBCZ-8-RL
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| Automotive | No |
| PPAP | No |
| Type | HDMI Transceiver |
| Number of Transmitters | 1 |
| Number of Receivers | 1 |
| Protocols Supported | HDCP |
| Minimum Dual Supply Voltage (V) | 3.14|1.71 |
| Typical Dual Supply Voltage (V) | 3.3|1.8 |
| Maximum Dual Supply Voltage (V) | 3.46|1.89 |
| Maximum Supply Current (mA) | 326.1(Typ) |
| Power Supply Type | Dual |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 70 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.01 |
| Package Width | 15 |
| Package Length | 15 |
| PCB changed | 260 |
| Standard Package Name | BGA |
| Supplier Package | CSP-BGA |
| Pin Count | 260 |
| Lead Shape | Ball |
Maiores detalhes de ADV7626 no site do fabricante:
https://www.analog.com/media/en/technical-documentation/data-sheets/ADV7626.pdf
Tags de ADV7626: ADV7626KBCZ-8-RL, ADV7626KBCZ-8, ADV7626KBCZ-8, ADV7626 KBCZ-8, HDMI Transceiver 1TX 1RX 260-Pin CSP-BGA T/R, CSPBGA-260, BGA-260 Video Interface IC, HDMI Transceiver IC, Analog Devices
ADV7626 IC 3GHz HDMI 2:2 cross point Transceiver On Screen BGA-260 HDMI Transceiver
Condição de ADV7626:
Novo em embalagem comercial
Garantia de ADV7626:
7 dias troca. Sem garantia após soldado
Outros PNs para este componente: ADV7626KBCZ-8-RL
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.01 |
| Automotive | No |
| PPAP | No |
| Type | HDMI Transceiver |
| Number of Transmitters | 1 |
| Number of Receivers | 1 |
| Protocols Supported | HDCP |
| Minimum Dual Supply Voltage (V) | 3.14|1.71 |
| Typical Dual Supply Voltage (V) | 3.3|1.8 |
| Maximum Dual Supply Voltage (V) | 3.46|1.89 |
| Maximum Supply Current (mA) | 326.1(Typ) |
| Power Supply Type | Dual |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 70 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.01 |
| Package Width | 15 |
| Package Length | 15 |
| PCB changed | 260 |
| Standard Package Name | BGA |
| Supplier Package | CSP-BGA |
| Pin Count | 260 |
| Lead Shape | Ball |
Maiores detalhes de ADV7626 no site do fabricante:
https://www.analog.com/media/en/technical-documentation/data-sheets/ADV7626.pdf
Tags de ADV7626: ADV7626KBCZ-8-RL, ADV7626KBCZ-8, ADV7626KBCZ-8, ADV7626 KBCZ-8, HDMI Transceiver 1TX 1RX 260-Pin CSP-BGA T/R, CSPBGA-260, BGA-260 Video Interface IC, HDMI Transceiver IC, Analog Devices
