AOC-IButton68 SUPERMICRO AOC-IButton68 Software MegaRAID 0, 1, 5, 10

Name: AOC-IButton68 SUPERMICRO AOC-IButton68 Software MegaRAID 0, 1, 5, 10
Brand: SUPERMICRO
SKU: AOC-IButton68
Price: 412.00 BRL
Availability: InStock

Type: EEPROM, Unique 64-bit Serial Number, Multidrop controller for 1-Wire net, Secure Hash Standar

clique para ampliar

*As imagens podem ser ilustrativas

avise-me quando disponível

R$ 412,00

à vista no Pix ou Boleto

ou R$ 432,77 em 1x no cartão (via site)

ou R$ 456,81 no cartão em até 10x sem juros (apenas na loja física)

R$ 412,00

à vista no Pix ou Boleto

R$ 432,77
em 1x no cartão (via site)

R$ 456,81 no cartão
em até 10x sem juros
(apenas na loja física)

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

84733099

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 84733099

Cotação PJ mais de uma unidade

Indicar AOC-IButton68

AOC-IButton68 SUPERMICRO AOC-IButton68 Software MegaRAID 0, 1, 5, 10
Type: EEPROM, Unique 64-bit Serial Number, Multidrop controller for 1-Wire net, Secure Hash Standar

Condição de AOC-IButton68: Novo em embalagem comercial

Garantia de AOC-IButton68: 12 meses direto com a Net Computadores

Features

512-bit SHA-1 Engine

Five General-Purpose Read/Write Registers

Monetary

One 64-bit Write-Only Secret

Secure

Secure Hash Standard

Unique 64-bit Serial Number

Key Features

Minimum 10 years of data retention at 85°C

Operating temperature range from -40°C to +85°C

Overdrive mode boosts communication speed to 125kbps

On-chip 512-bit SHA-1 engine to compute 160-bit MAC and to generate secrets

Reads and writes over a wide voltage range of 2.8V to 5.25V from -40°C to +85°C

Communicates to host with a single digital signal at 14.1kb per second using 1-Wire protocol

On-chip 16-bit CRC generator for safeguarding data transfers

Overdrive mode boosts communication speed to 125kbps

Operating temperature range from -40°C to +85°C

Minimum 10 years of data retention at 85°C

1128 bits of 5V EEPROM memory partitioned into four pages of 256 bits, a 64-bit write-only secret and up to five general purpose read/write registers

Write access requires knowledge of the secret and the capability of computing and transmitting a 160-bit MAC as authorization

Secret and data memory can be write-protected (all or page 0 only) or put in EPROM-emulation mode ("write to 0", page 1)

Common Features

Presence detector acknowledges when reader first applies voltage

Multidrop controller for 1-Wire net

Digital identification and information by momentary contact

Chip-based data carrier compactly stores information

Data can be accessed while affixed to object

Button shape is self-aligning with cup-shaped probes

Stainless steel case engraved with registration number withstands harsh environments

Easily affixed with self-stick adhesive backing, latched by its flange, or locked with a ring pressed onto its rim

Unique, factory-lasered and tested 64-bit registration number (8-bit family code + 48-bit serial number + 8-bit CRC tester) assures absolute traceability because no two parts are alike.

Memory
Size:	1K bits
Type:	EEPROM

Maiores detalhes de AOC-IButton68 no site do fabricante:
http://www.supermicro.com/products/accessories/addon/AOC-IButton68.cfm

Tags de AOC-IButton68: AOC-IButton68, Controladoras RAID, Acessórios e Baterias, SUPERMICRO, SUPERMICRO

AOC-IButton68 SUPERMICRO AOC-IButton68 Software MegaRAID 0, 1, 5, 10 Type: EEPROM, Unique 64-bit Serial Number, Multidrop controller for 1-Wire net, Secure Hash Standar

Condição de AOC-IButton68:
Novo em embalagem comercial

Garantia de AOC-IButton68:
12 meses direto com a Net Computadores

Features

512-bit SHA-1 Engine

Five General-Purpose Read/Write Registers

Monetary

One 64-bit Write-Only Secret

Secure

Secure Hash Standard

Unique 64-bit Serial Number

Key Features

Minimum 10 years of data retention at 85°C

Operating temperature range from -40°C to +85°C

Overdrive mode boosts communication speed to 125kbps

On-chip 512-bit SHA-1 engine to compute 160-bit MAC and to generate secrets

Reads and writes over a wide voltage range of 2.8V to 5.25V from -40°C to +85°C

Communicates to host with a single digital signal at 14.1kb per second using 1-Wire protocol

On-chip 16-bit CRC generator for safeguarding data transfers

Overdrive mode boosts communication speed to 125kbps

Operating temperature range from -40°C to +85°C

Minimum 10 years of data retention at 85°C

1128 bits of 5V EEPROM memory partitioned into four pages of 256 bits, a 64-bit write-only secret and up to five general purpose read/write registers

Write access requires knowledge of the secret and the capability of computing and transmitting a 160-bit MAC as authorization

Secret and data memory can be write-protected (all or page 0 only) or put in EPROM-emulation mode ("write to 0", page 1)

Common Features

Presence detector acknowledges when reader first applies voltage

Multidrop controller for 1-Wire net

Digital identification and information by momentary contact

Chip-based data carrier compactly stores information

Data can be accessed affixed to object

Button shape is self-aligning with cup-shaped probes

Stainless steel case engraved with registration number withstands harsh environments

Easily affixed with self-stick adhesive backing, latched by its flange, or locked with a ring pressed onto its rim

Unique, factory-lasered and tested 64-bit registration number (8-bit family code + 48-bit serial number + 8-bit CRC tester) assures absolute traceability because no two parts are alike.
