Condição de BNCVideoBalun: Novo em embalagem comercial
Garantia de BNCVideoBalun: 6 meses direto com a Net Computadores
|
Specs
|
1 Channel Passive Power-Video-Data/Audio PVD Transceiver
|
|
Video
|
Frequency respondFDC-6MHz
Common-ode/differential-mode rejectionF15HKz-6MHz 60dB type |
|
Video In/Out
|
BNC (Male) x 1 + BNC (Female) x1
|
|
Video Format
|
NTSC/PAL/CCIR/SECAM
|
|
Power Input
|
DC 12V
|
|
Audio/Data
|
Yes
|
|
Transmission Distance
|
Max. 600M (BW)
|
|
Impedance
|
Coaxial cable BNC Male: 75Ω
UTP RJ45 Data Connector: 100Ω |
|
Wire Type
|
Specification: 24AWG or UTP CAT5
Impedance: 100Ω±20% DC loop resistance: 18Ω/100M Difference Capacitance: 62pf/MiMAX.) |
|
Control
|
No
|
|
UTP Port
|
RJ45
|
|
Power Consumption
|
Not Required
|
|
Dimensions (mm)
|
43 x 22 x 20.5
|
|
Weight (g)
|
35
|
|
Environmental
|
Temperature Operating: -10 to +70
Storage: -30 to +70 Humidity: 0 to 95% |
Tags de BNCVideoBalun: video balun, power balun, vídeo balun, BNCVideoBalun, Balun, Balum, Balun de video, Balun de Vídeo, Balun UPT, UTP Balun, Balun para vídeo, Balun para video, balun CCTV, CCTV, CCTV Balun, Balun para camera, baluns, OEM, OEM
