200m a 400m Dual Mode Bluetooth LE, Bluetooth BR/EDR, 128K Flash
R$ 415,00
à vista no Pix ou Boleto
ou R$ 435,93 em 1x no cartão (via site)
ou R$ 460,15 no cartão em até 10x sem juros (apenas na loja física)
R$ 415,00
à vista no Pix ou Boleto
R$ 435,93
em 1x no cartão (via site)
R$ 460,15 no cartão
em até 10x sem juros
(apenas na loja física)
R$ 415,00
à vista no pix
Condição de BT121-A-V2: Novo em embalagem comercial
Garantia de BT121-A-V2: 3 meses direto com a Net Computadores
| Manufacturer: | Silicon Laboratories |
| Product Category: | Bluetooth Modules 802.15.1 |
| Series: | BT121 |
| Protocol: | Bluetooth 4.1 |
| Class: | Bluetooth Low Energy (BLE), Class 2 |
| Interface Type: | GPIO, I2C, SPI, UART |
| Output Power: | 12 dBm |
| Data Rate: | 3 Mb/s |
| Receiver Sensitivity: | 96 dBm |
| Frequency: | 2.44 GHz |
| Supply Voltage Min: | 2.2 V |
| Supply Voltage Max: | 3.6 V |
| Minimum Operating Temperature: | 40 C |
| Maximum Operating Temperature: | 85 C |
| Packaging: | Reel |
| Packaging: | Cut Tape |
| Packaging: | MouseReel |
| Antenna: | Chip |
| Antenna Connector Type: | Integrated |
| Brand: | Silicon Labs |
| Core: | ARM Cortex M0 |
| Features: | Integrated Bluetooth Smart Ready Stack, Internal Temperature Sensor |
| Frequency Range: | 2.402 GHz to 2.48 GHz |
| Height: | 2.2 mm |
| Length: | 13.9 mm |
| Memory Size: | 128 kB |
| Modulation Technique: | BDR, EDR, LE |
| Moisture Sensitive: | Yes |
| Mounting Style: | SMD/SMT |
| Operating Supply Voltage: | 2.2 V to 3.6 V |
| Product Type: | Bluetooth Modules |
| Range: | 200 m to 400 m |
| Sensitivity: | 96 dBm |
Maiores detalhes de BT121-A-V2 no site do fabricante:
https://www.silabs.com/documents/public/data-sheets/BT121-Datasheet.pdf
Tags de BT121-A-V2: BT121-A-V2, BT121-A, BT121-A V2, BT121, Silicon Labs BT121-A-V2 Bluetooth Chip 1.3, BT122-A-V2, BT122, BT122-A, BT122A V2, BT121-A-V2-IAP, RF module, modulo de desenvolvimento Bluetooth, modulo bluetooth para ioT, modulo RF para iot, modulo bluetoth para iot, ARM Cortex M0, Silicon Laboratories, Silicon Labs
BT121-A-V2 Modulo Bluetooth 4.1 802.15.1 Dual antena interna 200m a 400m Dual Mode Bluetooth LE, Bluetooth BR/EDR, 128K Flash
