24x 2.5 SAS/SATA Hot-Swap (não acompanha fonte)
R$ 471,00
à vista no Pix ou Boleto
ou R$ 494,81 em 1x no cartão (via site)
ou R$ 522,30 no cartão em até 10x sem juros (apenas na loja física)
R$ 471,00
à vista no Pix ou Boleto
R$ 494,81
em 1x no cartão (via site)
R$ 522,30 no cartão
em até 10x sem juros
(apenas na loja física)
Condição:
Novo em embalagem comercial
Garantia:
12 meses direto com a Net Computadores
NCM: 84733011
Condição de CSE-217HQ-R1620B: Novo em embalagem comercial
Garantia de CSE-217HQ-R1620B: 12 meses direto com a Net Computadores
| Main Specifications | |
| Device Type | SuperChassis 217HQ-R1620B |
| Dimensions (WxDxH) | 3.47 (88mm) x 17.25 (438mm) x 26.75 (679mm) |
| Enclosure Color | Black |
| Form Factor | 26.75 Depth 2U Rackmount Chassis - supports twin MB of size up to: 6.8 (172mm) x 16.64 (422mm) |
| Weight | 43 lbs / 68 lbs |
| Processor Support | Supports dual, single Intel / AMD processors |
| Expansion / Connectivity | |
| Expansion Slots Total (Free) | 1x Low-profile AOC slot (per node) |
| System Cooling | |
| Fans | 4x 80mm heavy duty fans with PWM fan speed controls |
| Front Panel | |
| Buttons | 4x Power On/Off button, 4x UID button |
| LEDs | 4x Power status LED, 4x UID LED, 4x Network activity LEDs, 4x System overheat / fan failed / power failed LED |
| Drive Bays | |
| Hot-swap | 6x Hot-swap 2.5 SATA drive bays / SAS or enterprise SATA HDD only recommended (per node) |
| Operating Environment (System) | |
| Operating Temperature Range | Operating Temperature Range 10 - 35C (50 - 95F) |
| Non-Operating Temperature Range -40 - 70C (-40 - 158F) | |
| Humidity Range 8 - 90% non-condensing | |
| Non-Operating Humidity Range 5 - 95% non-condensing | |
| Power Supply | |
| Certification | 80PLUS Platinum Certified |
| Power Supply | 1620W high-efficiency redundant power supply w/ PMBus |
| Regulatory Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, CCC Certification, EN 60950/IEC 60950-Compliant, Europe/CE Mark, Germany - TUV Certified |
| Power Supply | PWS-1K62P-1R / PDB-PT827-S2488 |
| Standard Parts List | |
| Accessory | MCP-420-21701-0N / MCP-320-82701-0B / MCP-180-00011-0N |
| Backplane | BPN-SAS-217HQ |
| Chassis | CSE-217HQ-R1620B |
| Drive Trays | MCP-220-00047-0B |
| Fans | FAN-0129L4 |
| Mounting Rails | MCP-290-00053-0N |
| Retention Modules/Bracket | MCP-120-00048-0N |
Maiores detalhes de CSE-217HQ-R1620B no site do fabricante:
http://www.supermicro.com/products/system/2u/2027/SYS-2027TR-H71QRF.cfm?parts=SH
Tags de CSE-217HQ-R1620B: CSE-217HQ-R1620B, CSE217HQR1620B, Supermicro SC217, SuperServer 2027TR-H71FRF, SuperServer 2027TR-H71QRF, SUPERMICRO
CSE-217HQ-R1620B Supermicro SuperServer 2U 4-Node Chassis 24x 2.5 SAS/SATA Hot-Swap (não acompanha fonte)
