Gabinetes / Gabinetes Server Torre / CSE-745TQ-R800B

CSE-745TQ-R800B Supermicro Gabinete Server 4U Torre EATX

Name: CSE-745TQ-R800B Supermicro Gabinete Server 4U Torre EATX
Brand: SUPERMICRO
SKU: CSE-745TQ-R800B
Price: 2282.00 BRL
Availability: InStock

8 Baias 3.5 SAS/SATA HOT-SWAP, 2x Fonte Redundante 800W, Suporta CPU Intel Xeon Dual

clique para ampliar

*As imagens podem ser ilustrativas

avise-me quando disponível

R$ 2.282,00

à vista no Pix ou Boleto

ou R$ 2.401,49 em 1x no cartão (via site)

ou R$ 2.534,90 no cartão em até 10x sem juros (apenas na loja física)

R$ 2.282,00

à vista no Pix ou Boleto

R$ 2.401,49
em 1x no cartão (via site)

R$ 2.534,90 no cartão
em até 10x sem juros
(apenas na loja física)

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

84733011

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 84733011

Cotação PJ mais de uma unidade

Indicar CSE-745TQ-R800B

CSE-745TQ-R800B Supermicro Gabinete Server 4U Torre EATX
8 Baias 3.5 SAS/SATA HOT-SWAP, 2x Fonte Redundante 800W, Suporta CPU Intel Xeon Dual

Condição de CSE-745TQ-R800B: Novo em embalagem comercial

Garantia de CSE-745TQ-R800B: 12 meses direto com a Net Computadores

• Form Factor: 4U Preto
• Chassis tecnologia Tool Less - Não necessita de ferramentas
• Suporta Motherboard 34,7 x 33cm
• ATX, EXTENDED ATX E ENHANCED EXTENDED ATX.
• Suporta CPU Intel Xeon Dual e Single ou AMD Opteron
• 2x Fonte 800Watts Redundante Alta Eficiência PWS-801-1R
• 8 x Baias 3.5 Hot-swap SAS / SATA
• 3 x Baias Periféricas - 2 x 5.25 e 1 x Floppy Drive 5.25
• 3 x Ventiladores 5000 RPM Hot-swap
• 2 x Exaustores 5000 RPM Hot-swap
• 7 x Slot de expansão PCI

Painel Frontal:
- 2x USB
- Power Switch
- Reset
- 6 LED Indicadores
- Trava com Filtro
- Monitoramento de sistema: Chassis Intrusion Switch

- Dimensões (A x C x P): 17,8 X 43,7 X 64,8cm
- Peso: 26,3kg

Specifications
- Mfr Part Number: CSE-745TQ-R800B
- Case Type: 4U Rackmount / Tower
- M/B Type: ATX, EATX; Supports Motherboard Size - 13.68 x 13.00 inch / 34.7 x 33.0 cm
- Processor Support: Dual, Single Intel / AMD Processors
- Drive Bays: 8x 3.5 Hot-swap SAS/SATA Drive Bays, 2x 5.25 Peripheral Drive Bays, 1x 5.25 Peripheral Drive Bay (fits 3.5 bay devices)
- Expansion Slots: 7x PCI Expansion slots
- Backplane: SAS / SATA Hard Drive Backplane w/ SES2
- Cooling System: 3x 5000RPM Hot-swap PWM Cooling Fans, 2x 5000RPM Hot-swap Rear Exhaust PWM Fans
- Front I/O Panel:
  - Buttons: Power On/Off, System Reset
  - LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat, Power Fail
  - Ports: 2x USB Ports
- Power Supply: 2x 800W 80 PLUS Platinum Certified High-efficiency (94%+) AC-DC Redundant Power Supply w/ PMBus and I2C
- Color: Black
- Dimensions (WxDxH): 7.0 x 25.5 x 17.2 inch / 178.0 x 648.0 x 437.0 mm

Motherboards:

X9DRH-7F	X9DRH-7TF
X9DRH-iF	X9DRH-iTF
X8DTN+	X8DTN+-LR
X8DTH-6	X8DTH-6F
X8DTH-i	X8DTH-iF
X8DT6	X8DT6-F
X8DTE	X8DTE-F
X8DT3	X8DT3-F
X8DTi	X8DTi-F
X8DTi-LN4F	X8DT3-LN4F
X8DTL-3	X8DTL-3F
X8DTL-i	X8DTL-iF
X8DTL-6	X8DTL-6F
X8DTL-6L	X8DTL-L
X8DA6	X8DAE
X8DA3	X8DAi
X8DAL-3	X8DAL-i
X8SIL	X8SIL-F
X8SIE	X8SIE-F
C7B75	X10SAE
X10SAT	X9DRH-iF-NV

Maiores detalhes de CSE-745TQ-R800B no site do fabricante:
http://www.supermicro.com.tw/products/chassis/4U/745/SC745TQ-R800B
