DBS2600CP4 Server Board Intel Dual Xeon E5 2600

Name: DBS2600CP4 Server Board Intel Dual Xeon E5 2600
Brand: Intel
SKU: DBS2600CP4
Price: 6960.00 BRL
Availability: InStock

Memória 16x DDR3 DDR3 ECC UDIMM 1600, RDIMM 1600, LRDIMM 1333 (max 512GB), Portas 4x SATA2, 2x SATA

clique para ampliar

*As imagens podem ser ilustrativas

avise-me quando disponível

R$ 6.960,00

à vista no Pix ou Boleto

ou R$ 7.325,47 em 1x no cartão (via site)

ou R$ 7.732,44 no cartão em até 10x sem juros (apenas na loja física)

R$ 6.960,00

à vista no Pix ou Boleto

R$ 7.325,47
em 1x no cartão (via site)

R$ 7.732,44 no cartão
em até 10x sem juros
(apenas na loja física)

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

84733041

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 84733041

Cotação PJ mais de uma unidade

Indicar DBS2600CP4

DBS2600CP4 Server Board Intel Dual Xeon E5 2600
Memória 16x DDR3 DDR3 ECC UDIMM 1600, RDIMM 1600, LRDIMM 1333 (max 512GB), Portas 4x SATA2, 2x SATA

Condição de DBS2600CP4: Novo em embalagem comercial

Garantia de DBS2600CP4: 12 meses direto com a Net Computadores

Essentials
• Status: Launched
• Launch Date: Q112
• Expected Discontinuance: Q117
• Limited 3-year Warranty: Yes
• Extended Warranty Available for Purchase (Select Countries): Yes
• On-Site Repair Available for Purchase (Select Countries): Yes, when integrated with Intel chassis.
• Nº of QPI Links: 2
• Board Form Factor: SSI EEB 12" x 13"
• Chassis Form Factor: Pedestal
• Socket: Socket R
• Integrated Systems Available: Yes
• Integrated BMC with IPMI IPMI: 2.0
• Rack-Friendly Board: Yes
• Embedded Options Available: Yes
• Supplemental SKU: No
• Max TDP: 135 W
• Included Items:
Intel® Server Board S2600CP4 supporting 16 DIMMs available in a 10-pack, 5-pack, or integrated in a system. The 5-pack also includes: (5) I/O shield, (5) DVD, (5) Quick Start Guide
• Description:
Intel® Server Board S2600CP4, Mainstream server board supporting two E5-2600 CPUs and 16 DIMMs with four 1Gb Ethernet ports.Six x8 electrical PCIe Gen3 IO slots. Up to 8 SCU ports plus 2 SATA 6Gb ports and 4 SATA 3Gb ports with storage activation key.
• Target Market: Small and Medium Business
Memory Specifications
• Max Memory Size (dependent on memory type): 512 GB
• Memory Types: DDR3 ECC UDIMM 1600, RDIMM 1600, LRDIMM 1333
• Nº of Memory Channels: 8
• Max Memory Bandwidth: 819 GB/s
• Physical Address Extensions: 46-bit
• Nº of DIMMs: 16
• ECC Memory Supported: Yes
Graphics Specifications
• Integrated Graphics: Yes
• Graphics Output: 15-pin VGA
• Intel® Clear Video Technology: No
• Dual Display Capable: No
• Discrete Graphics: Supported
Expansion Options
• PCI Express Revision: 3
• PCIe x8 Gen 3: 5
• PCIe x16 Gen 3: 1
• Intel® IO Expansion Module PCIe x8 Gen 3: 0
• Intel® Internal IO Expansion Module PCIe x8 Gen 3: 0
I/O Specifications
• USB Revision: USB 2.0
• Nº of USB Ports: 5
• USB 2.0 Configuration (Back + Internal): 4
• Nº of SATA Ports: 14
• Nº of eSATA Ports: 0
• RAID Configuration: Up to SW Raid 5 (LSI + RSTE)
• Nº of Serial Ports: 2
• Nº of LAN Ports: 4
• Integrated LAN: 4x 1GbE
• Embedded USB (eUSB) Solid State Drive Option: Yes
• Integrated SAS Ports: 8
Package Specifications
• Max CPU Configuration: 2
• Energy Star: Yes
• Low Halogen Options Available: See MDDS
Advanced Technologies
• Intel® Trusted Execution Technology: Yes
• AES New Instructions: Yes
• Intel® vPro Technology: No
• Intel® Active Management Technology: No
• Intel® AMT Version: False
• Intel® Remote Wake Technology: No
• Intel® Remote PC Assist Technology: No
• Intel® Remote Management Module Support: True
• Intel® Intelligent Power Node Manager: Yes
• Intel® CIRA Technology: No
• Intel® Anti-Theft Technology: No
• TPM: Yes
• Intel® TPM Version Intel®: TPM Version 1.2
• Intel® Quick Resume Technology: No
• Intel® Quiet System Technology: No
• Intel® HD Audio Technology: No
• Intel® AC97 Technology: No
• Intel® Matrix Storage Technology: Yes
• Intel® Fast Memory Access: Yes
• Intel® Flex Memory Access: Yes
• Intel® I/O Acceleration Technology: True

Maiores detalhes de DBS2600CP4 no site do fabricante:
http://ark.intel.com/products/56334/Intel-Server-Board-S2600CP4
