Rede / Switch até 10 Portas / EDS-408A-MM-SC-T

EDS-408A-MM-SC-T Moxa Switch 8 Portas Gerenciavel 6x 10/100BTX

Name: EDS-408A-MM-SC-T Moxa Switch 8 Portas Gerenciavel 6x 10/100BTX
Brand: MOXA
SKU: EDS-408A-MM-SC-T
Price: 14929.00 BRL
Availability: InStock

2x Portas Fibra Optica Multi-mode SC. RS232 Console Port. DC 24V

clique para ampliar

*As imagens podem ser ilustrativas

envio de 30 a 60 dias uteis

R$ 14.929,00

à vista no Pix ou Boleto

ou R$ 15.714,21 em 1x no cartão (via site)

ou R$ 16.587,23 no cartão em até 10x sem juros (apenas na loja física)

R$ 14.929,00

à vista no Pix ou Boleto

R$ 15.714,21
em 1x no cartão (via site)

R$ 16.587,23 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

85176239

R$ 14.929,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 85176239

Cotação PJ mais de uma unidade

Indicar EDS-408A-MM-SC-T

EDS-408A-MM-SC-T Moxa Switch 8 Portas Gerenciavel 6x 10/100BTX
2x Portas Fibra Optica Multi-mode SC. RS232 Console Port. DC 24V

Condição de EDS-408A-MM-SC-T: Novo em embalagem comercial

Garantia de EDS-408A-MM-SC-T: 12 meses direto com a Net Computadores

The EDS405A/408A are entrylevel 5 and 8port managed Ethernet switches designed especially for industrial applications. The switches support a variety of useful management s, such as Turbo Ring, ring coupling, portbased VLAN, QoS, RMON, bandwidth management, port mirroring, and warning by email or relay. The readytouse Turbo Ring can be set up easily using the webbased management interface, or with the DIP switches located on the top panel of the EDS405A/408A switches.
Features:

IPv6 Ready logo awarded (IPv6 Logo Committee certified)
DHCP Option 82 for IP address assignment with different policies (available soon)
Modbus/TCP industrial Ethernet protocol supported (available soon)
IEC 61850 GOOSE messaging compliance
PlugnPlay Turbo Ring (recovery time < 20 ms at full load) and RSTP/STP (IEEE 802.1w/D) capability
Portbased VLAN to ease network planning
QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
RMON for efficient network monitoring and proactive capability
SNMPv1/v2c/v3 for different levels of network management
Bandwidth management prevents unpredictable network status
Port mirroring for online debugging
Works with MXview industrial network management software

Technology
Standards	IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3x for Flow Control IEEE 802.1D2004 for Spanning Tree Protocol IEEE 802.1w for Rapid STP IEEE 802.1p for Class of Service IEEE 802.1Q for VLAN Tagging
Protocols	IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, TFTP, SNTP, SMTP, RARP, RMON, HTTP, Telnet, Syslog, DHCP Option 66/67/82, BootP, LLDP, EtherNet/IP, Modbus/TCP, IPv6, NTP Server/Client
MIB	MIBII, EthernetLike MIB, PBRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9
Flow Control	IEEE 802.3x flow control, back pressure flow control
Switch Properties
MAC Table Size	2 K (EDS405A), 8 K (EDS408A)
Packet Buffer Size	1 Mbit
Interface
Fiber Ports	100BaseFX ports (SC/ST connector)
RJ45 Ports	10/100BaseT(X) auto negotiation speed, Full/Half duplex mode SC, and auto MDI/MDIX connection
Console Port	RS232 (RJ45 connector)
DIP Switches	Turbo Ring, Master, Coupler, Reserve
LED Indicators	PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL, 10/100M
Alarm Contact	1 relay output with current carrying capacity of 1 A @ 24 VDC

Maiores detalhes de EDS-408A-MM-SC-T no site do fabricante:
https://www.moxa.com/en/products/industrial-network-infrastructure/ethernet-swit

Tags de EDS-408A-MM-SC-T: EDS-408A-MM-SC, EDS408AMMSC, switch 8 portas, gerenciavel, moxa, 10/100, EDS-408A-MM-SC, MOXA

EDS-408A-MM-SC-T Moxa Switch 8 Portas Gerenciavel 6x 10/100BTX 2x Portas Fibra Optica Multi-mode SC. RS232 Console Port. DC 24V

Condição de EDS-408A-MM-SC-T:
Novo em embalagem comercial

Garantia de EDS-408A-MM-SC-T:
12 meses direto com a Net Computadores

IPv6 Ready logo awarded (IPv6 Logo Committee certified)
DHCP Option 82 for IP address assignment with different policies (available soon)
Modbus/TCP industrial Ethernet protocol supported (available soon)
IEC 61850 GOOSE messaging compliance
PlugnPlay Turbo Ring (recovery time < 20 ms at full load) and RSTP/STP (IEEE 802.1w/D) capability
Portbased VLAN to ease network planning
QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
RMON for efficient network monitoring and proactive capability
SNMPv1/v2c/v3 for different levels of network management
Bandwidth management prevents unpredictable network status
Port mirroring for online debugging
Works with MXview industrial network management software

Technology
Standards	IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3x for Flow Control IEEE 802.1D2004 for Spanning Tree Protocol IEEE 802.1w for Rapid STP IEEE 802.1p for Class of Service IEEE 802.1Q for VLAN Tagging
Protocols	IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, TFTP, SNTP, SMTP, RARP, RMON, HTTP, Telnet, Syslog, DHCP Option 66/67/82, BootP, LLDP, EtherNet/IP, Modbus/TCP, IPv6, NTP Server/Client
MIB	MIBII, EthernetLike MIB, PBRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9
Flow Control	IEEE 802.3x flow control, back pressure flow control
Switch Properties
MAC Table Size	2 K (EDS405A), 8 K (EDS408A)
Packet Buffer Size	1 Mbit
Interface
Fiber Ports	100BaseFX ports (SC/ST connector)
RJ45 Ports	10/100BaseT(X) auto negotiation speed, Full/Half duplex mode SC, and auto MDI/MDIX connection
Console Port	RS232 (RJ45 connector)
DIP Switches	Turbo Ring, Master, Coupler, Reserve
LED Indicators	PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL, 10/100M
Alarm Contact	1 relay output with current carrying capacity of 1 A @ 24 VDC
