com 1 porta gigabite TP/SFP 190W não gerenciável
R$ 3.530,00
à vista no Pix ou Boleto
ou R$ 3.714,95 em 1x no cartão (via site)
ou R$ 3.921,34 no cartão em até 10x sem juros (apenas na loja física)
R$ 3.530,00
à vista no Pix ou Boleto
R$ 3.714,95
em 1x no cartão (via site)
R$ 3.921,34 no cartão
em até 10x sem juros
(apenas na loja física)
R$ 3.530,00
à vista no pix
Condição:
Novo em embalagem comercial
Garantia:
12 meses direto com a Net Computadores
NCM: 85176259
Condição de FGSW-2511P: Novo em embalagem comercial
Garantia de FGSW-2511P: 12 meses direto com a Net Computadores
| Hardware Specifications | |
|---|---|
| 10/100Mbps Ports | 24 10/100BASE-TX MDI/MDI-X RJ45 ports |
| Gigabit Ports | 1 10/100/1000BASE-T MDI/MDI-X RJ45 port |
| SFP Slot | 1 1000BASE-X SFP interface, shared with Gigabit RJ45 copper |
| PoE Inject Port | 24-port with 802.3at PoE injector (Port-1 to Port-24) |
| LED Display | System: -Power (Green) 10/100BASE-TX RJ45 Interface: -LNK/ACT (Green, Port-1 to Port-24) -PoE (Amber, Port-1 to Port-24) 10/100/1000BASE-T RJ45 and 1000BASE-X combo Interface: -LNK/ACT (Green, Port 25) |
| DIP Switch | 4 operation modes: Standard/QoS/VLAN/Extend |
| Switch Architecture | Store and Forward |
| MAC Address Table | 16K MAC address table with auto learning |
| Switch Fabric | 5.8Gbps |
| Switch Throughput | 5.06Mpps @64bytes |
| Maximum Packet Size | 16K bytes |
| Flow Control | Back pressure for half duplex IEEE 802.3x pause frame for full duplex |
| Power Requirements | AC 100~240V, 3A max. |
| Power Consumption | 205 watts, 699.5 BTU |
| Dimensions (W x D x H) | 440 x 200 x 45 mm |
| Weight | 2419 g |
| ESD Protection | Contact discharge of ±6KV DC Air discharge of ±8KV DC |
| Surge Immunity | ±4KV |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Power Supply Type | End-span |
| Power Pin Assignment | 1/2 ( ), 3/6 (-) |
| PoE Power Output | Per Port 52V DC, 600mA. max. 30 watts (IEEE 802.3at) Per Port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af) |
| PoE Power Budget | 190 watts |
| Number of PDs, 7 watts | 24 |
| Number of PDs, 15 watts | 12 |
| Number of PDs, 30 watts | 6 |
| Standard Conformance | |
| EMI Safety | CE, FCC |
| Standard Compliance | IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3z Energy Efficient Ethernet |
| Environment | |
| Operating Environment | 0 ~ 50 degrees C |
| Storage Environment | -10 ~ 70 degrees C |
| Operating Humidity | 5 ~ 95%, relative humidity, non-condensing |
| Storage Humidity | 5 ~ 95%, relative humidity, non-condensing |
Tags de FGSW-2511P: FGSW-2511P, FGSW2511P, FGSW 2511P, 24-Port 10/100BASE-TX 802.3at PoE + 1-Port Gigabit TP/SFP Combo Ethernet Switch, switch 24 portas planet, switch 24 portas 10/100 base tx 802.3at, switch nao gerenciavel, switch 24 portas rj45, switch porta gigabit rj45, PLANET Technology
FGSW-2511P Planet switch 24 portas 10/100 base-TX802.3at PoE com 1 porta gigabite TP/SFP 190W não gerenciável
Condição de FGSW-2511P:
Novo em embalagem comercial
Garantia de FGSW-2511P:
12 meses direto com a Net Computadores
| Hardware Specifications | |
|---|---|
| 10/100Mbps Ports | 24 10/100BASE-TX MDI/MDI-X RJ45 ports |
| Gigabit Ports | 1 10/100/1000BASE-T MDI/MDI-X RJ45 port |
| SFP Slot | 1 1000BASE-X SFP interface, shared with Gigabit RJ45 copper |
| PoE Inject Port | 24-port with 802.3at PoE injector (Port-1 to Port-24) |
| LED Display | System: -Power (Green) 10/100BASE-TX RJ45 Interface: -LNK/ACT (Green, Port-1 to Port-24) -PoE (Amber, Port-1 to Port-24) 10/100/1000BASE-T RJ45 and 1000BASE-X combo Interface: -LNK/ACT (Green, Port 25) |
| DIP Switch | 4 operation modes: Standard/QoS/VLAN/Extend |
| Switch Architecture | Store and Forward |
| MAC Address Table | 16K MAC address table with auto learning |
| Switch Fabric | 5.8Gbps |
| Switch Throughput | 5.06Mpps @64bytes |
| Maximum Packet Size | 16K bytes |
| Flow Control | Back pressure for half duplex IEEE 802.3x pause frame for full duplex |
| Power Requirements | AC 100~240V, 3A max. |
| Power Consumption | 205 watts, 699.5 BTU |
| Dimensions (W x D x H) | 440 x 200 x 45 mm |
| Weight | 2419 g |
| ESD Protection | Contact discharge of ±6KV DC Air discharge of ±8KV DC |
| Surge Immunity | ±4KV |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Power Supply Type | End-span |
| Power Pin Assignment | 1/2 ( ), 3/6 (-) |
| PoE Power Output | Per Port 52V DC, 600mA. max. 30 watts (IEEE 802.3at) Per Port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af) |
| PoE Power Budget | 190 watts |
| Number of PDs, 7 watts | 24 |
| Number of PDs, 15 watts | 12 |
| Number of PDs, 30 watts | 6 |
| Standard Conformance | |
| EMI Safety | CE, FCC |
| Standard Compliance | IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3z Energy Efficient Ethernet |
| Environment | |
| Operating Environment | 0 ~ 50 degrees C |
| Storage Environment | -10 ~ 70 degrees C |
| Operating Humidity | 5 ~ 95%, relative humidity, non-condensing |
| Storage Humidity | 5 ~ 95%, relative humidity, non-condensing |
Tags de FGSW-2511P: FGSW-2511P, FGSW2511P, FGSW 2511P, 24-Port 10/100BASE-TX 802.3at PoE + 1-Port Gigabit TP/SFP Combo Ethernet Switch, switch 24 portas planet, switch 24 portas 10/100 base tx 802.3at, switch nao gerenciavel, switch 24 portas rj45, switch porta gigabit rj45, PLANET Technology
