10/100/1000Base-T to mini GBIC (SFP) (LC,MM/SM) distância depende do módulo
R$ 1.638,00
à vista no Pix ou Boleto
ou R$ 1.723,60 em 1x no cartão (via site)
ou R$ 1.819,36 no cartão em até 10x sem juros (apenas na loja física)
R$ 1.638,00
à vista no Pix ou Boleto
R$ 1.723,60
em 1x no cartão (via site)
R$ 1.819,36 no cartão
em até 10x sem juros
(apenas na loja física)
R$ 1.638,00
à vista no pix
Condição:
Novo em embalagem comercial
Garantia:
12 meses direto com a Net Computadores
NCM: 85176294
Condição de GT-905A: Novo em embalagem comercial
Garantia de GT-905A: 12 meses direto com a Net Computadores
| Hardware Specifications | |
|---|---|
| Standards | IEEE 802.3, 10BASE-T IEEE 802.3u, 100BASE-TX/FX IEEE 802.3ab, 1000BASE-T IEEE 802.3z, 1000BASE-SX/LX |
| Ports | 1 x 10/100/1000BASE-T port, 1 x 1000BASE-SX/LX port |
| Copper Interface | RJ-45 port (Auto-MDI/MDI-X) Twisted Pair |
| Optic Interface | GT-905A: SFP (100/1000X) |
| Optic Wavelength | GT-905A: N/A |
| Launch Power(dBm) Max. | GT-905A: N/A |
| Launch Power(dBm) Min. | GT-905A: N/A |
| Receive Sensitivity | GT-905A: N/A |
| Maximum Input power | GT-905A: N/A |
| Speed Twisted-pair | 10/20Mbps for Half / Full-Duplex 100/200Mbps for Half / Full Duplex 2000Mbps for Full-Duplex |
| Speed Fiber-optic | 2000Mbps for Full-Duplex |
| Cable Twisted-pair | 10BASE-T: 2-pair UTP Cat. 3,4,5, up to 100 m 100BASE-TX: 2-pair UTP Cat. 5, up to 100 m 1000BASE-T: 4-pair STP Cat 5 up to 100m |
| Cable Fiber-optic Cable | - 50/125-m or 62.5/125-m multi-mode fiber cable, up to 220/550m. - 9/125-m single-mode cable, provides long distance for 10/15/20/30/40/50/60/70/120km (very on fiber transceiver or SFP module) |
| LED Indicator | - PWR, - TP LINK/ACT, 1000 - Fiber LINK/ACT |
| Power Consumption | 4 watts/ 13 BTU (maximum) |
| Power Input | DC 5V / 2A |
| Dimensions (W x D x H) | 94 x 70 x 26 mm |
| Operating Environment | Temperature: 0~50 degrees C; Humidity: 5~90% non-condensing |
| Storage Environment | Temperature: -40~70 degrees C; Humidity: 5~90% non-condensing |
| Emissions | FCC Class A, CE Class A |
| Ordering Information | |
|---|---|
| GT-905A | 10/100/1000BASE-T to 100/1000BASE-X Managed Media Converter (mini-GBIC, SFP)-distance depend on SFP module |
Maiores detalhes de GT-905A no site do fabricante:
https://planet.com.tw/storage/products/43643/C-GT-80x_s.pdf
Tags de GT-905A: GT-905A, GT905A, Conversor de Fibra Planet, Conversor de Fibra SFP, PLANET Technology, MGB-LX, conversor de midia monomodo LC utilizando MGB-LX, conversor monomodo lc utilizando MGB-LX, PLANET Technology
GT-905A Planet Conversor de Mídia SFP RJ45 10/100/1000Base-T to mini GBIC (SFP) (LC,MM/SM) distância depende do módulo
Condição de GT-905A:
Novo em embalagem comercial
Garantia de GT-905A:
12 meses direto com a Net Computadores
| Hardware Specifications | |
|---|---|
| Standards | IEEE 802.3, 10BASE-T IEEE 802.3u, 100BASE-TX/FX IEEE 802.3ab, 1000BASE-T IEEE 802.3z, 1000BASE-SX/LX |
| Ports | 1 x 10/100/1000BASE-T port, 1 x 1000BASE-SX/LX port |
| Copper Interface | RJ-45 port (Auto-MDI/MDI-X) Twisted Pair |
| Optic Interface | GT-905A: SFP (100/1000X) |
| Optic Wavelength | GT-905A: N/A |
| Launch Power(dBm) Max. | GT-905A: N/A |
| Launch Power(dBm) Min. | GT-905A: N/A |
| Receive Sensitivity | GT-905A: N/A |
| Maximum Input power | GT-905A: N/A |
| Speed Twisted-pair | 10/20Mbps for Half / Full-Duplex 100/200Mbps for Half / Full Duplex 2000Mbps for Full-Duplex |
| Speed Fiber-optic | 2000Mbps for Full-Duplex |
| Cable Twisted-pair | 10BASE-T: 2-pair UTP Cat. 3,4,5, up to 100 m 100BASE-TX: 2-pair UTP Cat. 5, up to 100 m 1000BASE-T: 4-pair STP Cat 5 up to 100m |
| Cable Fiber-optic Cable | - 50/125-m or 62.5/125-m multi-mode fiber cable, up to 220/550m. - 9/125-m single-mode cable, provides long distance for 10/15/20/30/40/50/60/70/120km (very on fiber transceiver or SFP module) |
| LED Indicator | - PWR, - TP LINK/ACT, 1000 - Fiber LINK/ACT |
| Power Consumption | 4 watts/ 13 BTU (maximum) |
| Power Input | DC 5V / 2A |
| Dimensions (W x D x H) | 94 x 70 x 26 mm |
| Operating Environment | Temperature: 0~50 degrees C; Humidity: 5~90% non-condensing |
| Storage Environment | Temperature: -40~70 degrees C; Humidity: 5~90% non-condensing |
| Emissions | FCC Class A, CE Class A |
| Ordering Information | |
|---|---|
| GT-905A | 10/100/1000BASE-T to 100/1000BASE-X Managed Media Converter (mini-GBIC, SFP)-distance depend on SFP module |
Maiores detalhes de GT-905A no site do fabricante:
https://planet.com.tw/storage/products/43643/C-GT-80x_s.pdf
Tags de GT-905A: GT-905A, GT905A, Conversor de Fibra Planet, Conversor de Fibra SFP, PLANET Technology, MGB-LX, conversor de midia monomodo LC utilizando MGB-LX, conversor monomodo lc utilizando MGB-LX, PLANET Technology
