MCU 8-bit S08 CISC 16KB Flash 3.3V/5V 48-Pin LQFP Tray
R$ 25,00
à vista no Pix ou Boleto
ou R$ 26,32 em 1x no cartão (via site)
ou R$ 27,78 no cartão em até 10x sem juros (apenas na loja física)
R$ 25,00
à vista no Pix ou Boleto
R$ 26,32
em 1x no cartão (via site)
R$ 27,78 no cartão
em até 10x sem juros
(apenas na loja física)
R$ 25,00
à vista no pix
Condição de MC9S08PA16VLC: Novo em embalagem comercial
Garantia de MC9S08PA16VLC: 3 meses direto com a Net Computadores
Outros PNs para este item: MC9S08, MC9S08MP16
| Manufacturer: | NXP |
| Product Category: | 8-bit Microcontrollers - MCU |
| Series: | S08MP |
| Mounting Style: | SMD/SMT |
| Package / Case: | LQFP-48 |
| Core: | S08 |
| Program Memory Size: | 16 kB |
| Data Bus Width: | 8 bit |
| ADC Resolution: | 12 bit |
| Maximum Clock Frequency: | 51.34 MHz |
| Number of I/Os: | 40 I/O |
| Data RAM Size: | 1 kB |
| Supply Voltage - Min: | 2.7 V |
| Supply Voltage - Max: | 5.5 V |
| Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | 105 C |
| Packaging: | Tray |
| Brand: | NXP Semiconductors |
| Data RAM Type: | RAM |
| Interface Type: | SCI |
| Moisture Sensitive: | Yes |
| Number of ADC Channels: | 13 Channel |
| Number of Timers/Counters: | 2 Timer |
| Operating Supply Voltage: | 2.7 V to 5.5 V |
| Processor Series: | MC9S08MP16 |
| Product: | MCU |
| Product Type: | 8-bit Microcontrollers - MCU |
| Program Memory Type: | Flash |
Maiores detalhes de MC9S08PA16VLC no site do fabricante:
https://www.nxp.com/docs/en/data-sheet/MC9S08MP16DS.pdf
Tags de MC9S08PA16VLC: S08MP, MC9S08MP16, MC9S08P, MC9S08PA, MC9S08, MC9S08PA16VLC, LPC2368FBD100K, LPC2368, LPC2368FBd100, nsd1728d, ARM7 series Microcontroller, MCU LPC2000, ARM LPC2000, ARM7TDMI-S, 10-bit ADC, 10bit ADC, conversor AD 10bits, LPC2368FBD100,551, LPC2368FBD100-551, CPU RL78 core, microcontrolador MCU RL78, microprocessador de desenvolvimento, RL78/G13-Starter-Kit, RENESAS R8C controller, RENESAS R5F controller, M3062LFGPGP, M3062LFGPGP-U3C, M3062LFGPGP-U5C, M16C/60, 16-bit Microcontrollers - MCU, M16C M16C/60/62P, M3062, M3062L, M3062LF, M3062LFGPGPU3C, QSK-62P PLUS, QUICK START KIT M16C/62P EVAL BD, M16C, SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER, MCU Arm, MCU Arm7, MCU 10Bit, LPC23, ARM7TDMIS, NXP Semiconductors, ARM Microcontrollers, NXP Semiconductor
MC9S08PA16VLC Microcontrolador MCU 8BIT 16KB FLASH 48LQFP MCU 8-bit S08 CISC 16KB Flash 3.3V/5V 48-Pin LQFP Tray
Condição de MC9S08PA16VLC:
Novo em embalagem comercial
Garantia de MC9S08PA16VLC:
3 meses direto com a Net Computadores
Outros PNs para este componente: MC9S08, MC9S08MP16
| Manufacturer: | NXP |
| Product Category: | 8-bit Microcontrollers - MCU |
| Series: | S08MP |
| Mounting Style: | SMD/SMT |
| Package / Case: | LQFP-48 |
| Core: | S08 |
| Program Memory Size: | 16 kB |
| Data Bus Width: | 8 bit |
| ADC Resolution: | 12 bit |
| Maximum Clock Frequency: | 51.34 MHz |
| Number of I/Os: | 40 I/O |
| Data RAM Size: | 1 kB |
| Supply Voltage - Min: | 2.7 V |
| Supply Voltage - Max: | 5.5 V |
| Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | 105 C |
| Packaging: | Tray |
| Brand: | NXP Semiconductors |
| Data RAM Type: | RAM |
| Interface Type: | SCI |
| Moisture Sensitive: | Yes |
| Number of ADC Channels: | 13 Channel |
| Number of Timers/Counters: | 2 Timer |
| Operating Supply Voltage: | 2.7 V to 5.5 V |
| Processor Series: | MC9S08MP16 |
| Product: | MCU |
| Product Type: | 8-bit Microcontrollers - MCU |
| Program Memory Type: | Flash |
Maiores detalhes de MC9S08PA16VLC no site do fabricante:
https://www.nxp.com/docs/en/data-sheet/MC9S08MP16DS.pdf
Tags de MC9S08PA16VLC: S08MP, MC9S08MP16, MC9S08P, MC9S08PA, MC9S08, MC9S08PA16VLC, LPC2368FBD100K, LPC2368, LPC2368FBd100, nsd1728d, ARM7 series Microcontroller, MCU LPC2000, ARM LPC2000, ARM7TDMI-S, 10-bit ADC, 10bit ADC, conversor AD 10bits, LPC2368FBD100,551, LPC2368FBD100-551, CPU RL78 core, microcontrolador MCU RL78, microprocessador de desenvolvimento, RL78/G13-Starter-Kit, RENESAS R8C controller, RENESAS R5F controller, M3062LFGPGP, M3062LFGPGP-U3C, M3062LFGPGP-U5C, M16C/60, 16-bit Microcontrollers - MCU, M16C M16C/60/62P, M3062, M3062L, M3062LF, M3062LFGPGPU3C, QSK-62P PLUS, QUICK START KIT M16C/62P EVAL BD, M16C, SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER, MCU Arm, MCU Arm7, MCU 10Bit, LPC23, ARM7TDMIS, NXP Semiconductors, ARM Microcontrollers, NXP Semiconductor
