MKL28Z512VLL7 IC MCU Arm Cortex M0+ 32BIT 72Mhz 512KB 100LQFP

*As imagens podem ser ilustrativas

IC MCU Arm Cortex M0+ 32BIT 72Mhz 512KB 100LQFP

em estoque, envio imediato

R$ 45,00

à vista no Pix ou Boleto

ou R$ 46,43 em 1x no cartão (via site)

ou R$ 49,01 no cartão em até 10x sem juros (apenas na loja física)

R$ 45,00

à vista no Pix ou Boleto

R$ 46,43
em 1x no cartão (via site)

R$ 49,01 no cartão
em até 10x sem juros
(apenas na loja física)

Comprar

Condição:

Novo em embalagem comercial

Garantia:

3 meses direto com a Net Computadores

NCM:

85423190

R$ 45,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
3 meses direto com a Net Computadores

NCM: 85423190

Comprar via
MERCADO LIVRE

Somos MercadoLivre Platinum
Comprar Parcelado no MercadoLivre
Comprar à Vista no MercadoLivre

Cotação PJ mais de uma unidade

Indicar MKL28Z512VLL7

MKL28Z512VLL7 IC MCU Arm Cortex M0+ 32BIT 72Mhz 512KB 100LQFP

Condição de MKL28Z512VLL7: Novo em embalagem comercial

Garantia de MKL28Z512VLL7: 3 meses direto com a Net Computadores

Outros PNs para este item: MKL28Z512VLL7, MKL28Z512VLL7R

Kinetis KL28Zxxx with 512KB Flash and 128KB SRAM 72 MHz CortexM0 based Microcontroller.

MKL28Z512VLL7R
KINETIS L 32BIT MCU
ARM CORTEXM0 CORE
512KB FLASH
128KB RAM
72MHZ
USB OTG
100LQFP
REEL 13 Q2 DP
TR ROHS COMPLIANT: YES

Supports ultra low power Arm based microcontroller with crystalless USB feature, large flash and RAM, evolutionary lowpower peripherals and security features. This is an ideal solution for Sensor Hub applications, Bluetooth, WiFi connectivity, Smart Energy, Internet of Things, and Edge and Concentrator. This device offers:

128KB SRAM for data processing and connectivity stack
Ultra low dynamic and static power consumption with smart peripherals for low power applications
Advanced LPI2C and LPSPI supporting asynchronous DMA master data transition
FlexIO for flexible and high performance interfaces
Crypto acceleration with AES/DES/3DES/MD5/SHA and TRNG
USB FS 2.0 device operation without need of external crystal

Core
Arm CortexM0 cores up to 72 MHz in Normal mode and 96 MHz in High Speed mode

Memories
Up to 512 KB program flash memory
128 KB SRAM
32 KB ROM with builtin bootloader

System peripherals
8channel DMA controller
Independent clocked Watchdog
Lowleakage wakeup unit
SWD debug interface and Micro Trace Buffer
Bit Manipulation Engine
Memory Mapped Divide and Square Root module (MMDDVSQ)
Cyclic Redundancy Check (CRC) module
Nested Vector Interrupt Controller (NVIC) supports 32 interrupt vectors
Additional peripheral interrupt support via Interrupt Multiplexer (INTMUX)

Clocks
System Clock Generator module that includes the following clock sources:
48 to 60 MHz high accuracy fast internal reference clock (FIRC)
3240 kHz, or 332 MHz crystal oscillator
   1 kHz LPO clock
   8/2 MHz slow internal reference clock (SIRC)
   Peripheral Clock Control (PCC) module that supports asynchronous clocking and clock divide options for peripherals.

Communication interfaces
Three 16bit Low Power Serial Peripheral Interface (LPSPI) modules
One EMVSIM module supporting EMV version 4.3, ISO7816
Three LPUART modules Three LPI2C modules supporting up to 5 Mbit/s
One SAI module supporting I2S
One FlexIO module emulating UART, SPI, I2S, camera interface, and Motorola 68K/Intel 8080 bus
USB FS 2.0 device operation without need of external crystal

Analog Modules
16bit, 24channel SAR ADC with internal voltage reference
Two Highspeed analog comparators each containing a 6bit DAC and programmable reference input
One 12bit DAC
1.2 V and 2.1 V voltage references (Vref)

Timers
One 6channel Timer/PWM module
Two 2channel Timer/PWM modules
Two lowpower timers
Two periodic interrupt timers
Secure Real time clock
56bit software time stamp timer at 1MHz

Security and integrity modules
80bit unique identification number per chip
MMCAU supports acceleration of the DES, 3DES, AES, MD5, SHA1, and SHA256 algorithms
True Random Number Generator (TRNG)

Operating Characteristics
Voltage range: 1.71 to 3.6 V
Temperature range: 40 to 105 C

TYPE	DESCRIPTION
Category	Integrated Circuits (ICs) Embedded Microcontrollers
Mfr	NXP USA Inc.
Series	Kinetis KL2
Package	Tape e Reel (TR)
Product Status	Active
Core Processor	ARM CortexM0
Core Size	32Bit Single Core
Speed	72MHz
Connectivity	I²C, FlexIO, SPI, UART/USART, USB
Peripherals	DMA, I²S, PWM, WDT
Number of I/O	90
Program Memory Size	512KB (512K x 8)
Program Memory Type	FLASH
EEPROM Size
RAM Size	128K x 8
Voltage Supply (Vcc/Vdd)	1.71V ~ 3.6V
Data Converters	A/D 27x16b SAR; D/A 1x12b
Oscillator Type	Internal
Operating Temperature	40C ~ 105C (TA)
Mounting Type	Surface Mount
Package / Case	100LQFP
Supplier Device Package	100LQFP (14x14)
Base Product Number	MKL28Z512

Maiores detalhes de MKL28Z512VLL7 no site do fabricante:
https://www.nxp.com/docs/en/data-sheet/MKL28Z512Vxx7.pdf

Tags de MKL28Z512VLL7: ARM Microcontrollers, MKL28Z512VLL7R, MKL28Z512VLL7, microcontrolador Arm CortexM0+, microcontrolador Arm Cortex M0, microcontrolador Arm Cortex M0+, MKL28Z512VLL7, MKL25Z128VLK4, Microcontroller MCU Arm Cortex, microcontrolador 32Bit, microcontrolador Arm 32Bits, Kinetis L 32-bit MCU, ARM Cortex-M0+ core, 512KB Flash, 128KB RAM, 72MHz, USB OTG, 100LQFP, LPC2368FBD100, LPC1788FBD208, NXP Semiconductor, MKL28Z512VLL7, MKL28Z512, Embedded Microcontroller, Kinetis KL2, MKL28Z512VLL7, NXP Semiconductor

MKL28Z512VLL7 IC MCU Arm Cortex M0+ 32BIT 72Mhz 512KB 100LQFP

Condição de MKL28Z512VLL7:
Novo em embalagem comercial

Garantia de MKL28Z512VLL7:
3 meses direto com a Net Computadores

Outros PNs para este componente: MKL28Z512VLL7, MKL28Z512VLL7R

Kinetis KL28Zxxx with 512KB Flash and 128KB SRAM 72 MHz CortexM0 based Microcontroller.

MKL28Z512VLL7R
KINETIS L 32BIT MCU
ARM CORTEXM0 CORE
512KB FLASH
128KB RAM
72MHZ
USB OTG
100LQFP
REEL 13 Q2 DP
TR ROHS COMPLIANT: YES

TYPE	DESCRIPTION
Category	Integrated Circuits (ICs) Embedded Microcontrollers
Mfr	NXP USA Inc.
Series	Kinetis KL2
Package	Tape e Reel (TR)
Product Status	Active
Core Processor	ARM CortexM0
Core Size	32Bit Single Core
Speed	72MHz
Connectivity	I²C, FlexIO, SPI, UART/USART, USB
Peripherals	DMA, I²S, PWM, WDT
Number of I/O	90
Program Memory Size	512KB (512K x 8)
Program Memory Type	FLASH
EEPROM Size
RAM Size	128K x 8
Voltage Supply (Vcc/Vdd)	1.71V ~ 3.6V
Data Converters	A/D 27x16b SAR; D/A 1x12b
Oscillator Type	Internal
Operating Temperature	40C ~ 105C (TA)
Mounting Type	Surface Mount
Package / Case	100LQFP
Supplier Device Package	100LQFP (14x14)
Base Product Number	MKL28Z512
