Ethernet Interface
Number of Ports	1
Speed	10/100 Mbps, auto MDI/MDIX
Connector	RJ45
Magnetic Isolation Protection	1.5 KV builtin
WLAN Interface
Standard Compliance	802.11a/b/g/n
Network Modes	Infrastructure, AdHoc
Transmit Power	802.11a: 14 dBm (typical) 802.11b: 17 dBm (typical) 802.11g: 15 dBm (typical)
Receive Sensitivity	80 dBm
Radio Frequency Type	DSSS/OFDM
Transmission Rate	802.11a: 54 Mbps 802.11b: 11 Mbps 802.11g: 54 Mbps (max.) with auto fallback (54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps)
Transmission Distance	Up to 100 meters (in open areas)
Wireless Security	WEP: 64bit/128bit data encryption WPA, WPA2, 802.11i: Enterprise mode and PreShare Key (PSK) mode Encryption: 128bit TKIP/AESCCMP EAPTLS, PEAP/GTC, PEAP/MD5, PEAP/MSCHAPV2, EAPTTLS/PAP, EAPTTLS/CHAP, EAPTTLS/MSCHAP, EAPT
Antenna Connector	Reverse SMA
Serial Interface
Number of Ports	NPort W2150A: 1
Serial Standards	RS232/422/485 (DB9 male connector)
Offline Port Buffering	NPort W2150A: 20 MB
Serial Line Surge Protection	1KV (level 2)
Serial Communication Parameters
Data Bits	5, 6, 7, 8
Stop Bits	1, 1.5, 2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS, XON/XOFF
Baudrate	50 bps to 921.6 Kbps
Serial Data Log	64 KB
Serial Signals
RS232	TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS422	TxD , TxD, RxD , RxD, GND
RS4854w	TxD , TxD, RxD , RxD, GND
RS4852w	Data , Data, GND
Software
Network Protocols	ICMP, IP, TCP, UDP, DHCP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, SNTP, SSH, HTTPS
Configuration Options	Web Console, Serial Console, Telnet Console, Windows Utility
Secure Configuration Options	HTTPS, SSH
Windows RealCOM Drivers	Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/ 7 x86/x64, Embedded CE 5.0/6.0, XP Embedded
Fixed TTY Drivers	SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HPUX 11i
Linux Real TTY Drivers	2.4.x, 2.6.x, 3.0.x
Utilities	NPort Search Utility and NPort Windows Driver manager
Management	SNMP MIBII
Physical Characteristics
Housing	Aluminum sheet metal (1 mm)
Weight	780 g
Dimensions	Without ears or antenna: 77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in) With ears, without antenna: 100 x 111 x 26 mm (3.94 x 4.37 x 1.02 in) Antenna Length: 109.79 mm (4.32 in)
Environmental Limits
Operating Temperature	Standard Models: 0 to 55C (32 to 131F) Wide Temp. Models: 40 to 75C (40 to 167F)
Storage Temperature	40 to 85C (4 to 185F)
Ambient Relative Humidity	5 to 95% (noncondensing)
Power Requirements
Input Voltage	12 to 48 VDC
Power Consumption	237 mA @ 12 V, 125 mA @ 24 V, 50 mA @ 48 V
Standards and Certifications
Safety	UL 609501, EN 609501
EMC	CE, FCC
EMI	FCC Part 15 Subpart B Class A, FCC Subpart C/E, VCCI
EMS	EN 55022 Class A
Radio	CE (ETSI EN 301 893, ETSI EN 300 328), ARIB RCR STD33, ARIB STD66
Power Line Surge Protection	2 KV (level 3)
Reliability
Alert Tool	RTC (realtime clock)
Automatic Reboot Trigger	Builtin WDT (watchdog timer)
MTBF (mean time between failures)	NPort W2150A: 383,187 hrs

Tags de NPORTW2150A-US: NPORTW2150A-US, NPORT W2150A-US, NPORTW2150A, NPORT W2150A, Moxa 1 port RS232/422/485 DB9M wireless device server 3-in-1 w/802.11 a/b/g/n, 1 Port RS232/422/485 Serial to WiFi Device Server, =NPORTW2150A-US, MOXA

NPORTW2150A-US Moxa wireless device server 3 in 1 1 Port RS232/422/485 serial to wifi device server

Condição de NPORTW2150A-US:
Novo em embalagem comercial

Garantia de NPORTW2150A-US:
12 meses direto com a Net Computadores
