encapsulamento MSOP8
R$ 64,00
à vista no Pix ou Boleto
ou R$ 66,55 em 1x no cartão (via site)
ou R$ 70,25 no cartão em até 10x sem juros (apenas na loja física)
R$ 64,00
à vista no Pix ou Boleto
R$ 66,55
em 1x no cartão (via site)
R$ 70,25 no cartão
em até 10x sem juros
(apenas na loja física)
Condição de OPA2350EA/2K5: Novo em embalagem comercial
Garantia de OPA2350EA/2K5: 7 dias troca. Sem garantia após soldado
Outros PNs para este item: OPA2350EA/2K5G4This part number is identical to the part number listed above. You can only order quantities of the part number listed above.
| Manufacturer: | Texas Instruments |
| Product Category: | High Speed Operational Amplifiers |
| RoHS: | |
| Series: | OPA2350 |
| Number of Channels: | 2 Channel |
| GBP Gain Bandwidth Product: | 38 MHz |
| SR Slew Rate: | 22 V/us |
| Voltage Gain dB: | 122 dB |
| CMRR Common Mode Rejection Ratio: | 90 dB |
| Output Current per Channel: | 40 mA |
| Ib Input Bias Current: | 10 pA |
| Vos Input Offset Voltage: | 150 uV |
| Supply Voltage Max: | 5.5 V |
| Supply Voltage Min: | 2.7 V |
| Operating Supply Current: | 5.2 mA |
| Minimum Operating Temperature: | 40 C |
| Maximum Operating Temperature: | 85 C |
| Mounting Style: | SMD/SMT |
| Package / Case: | VSSOP8 |
| Packaging: | Reel |
| Packaging: | Cut Tape |
| Packaging: | MouseReel |
| Brand: | Texas Instruments |
| en Input Voltage Noise Density: | 7 nV/sqrt Hz |
| Height: | 0.97 mm |
| Input Type: | RailtoRail |
| Length: | 3 mm |
| Moisture Sensitive: | Yes |
| Operating Supply Voltage: | 5.5 V |
Maiores detalhes de OPA2350EA/2K5 no site do fabricante:
https://www.ti.com/lit/ds/symlink/opa2350.pdf?ts=1679035351687eref_url=https%253
Tags de OPA2350EA/2K5: OPA2350EA/2K5, OPA2350EA, OPA2350, OPA2350E, D50 99M4, OPA2350EA/2K5G4This part number is identical to the part number listed above. You can only order quantities of the part number listed above, OPA350, OPA4350, MSOP8, Texas Instruments
OPA2350EA/2K5 Amplificador operacional high speed low noise encapsulamento MSOP8
Condição de OPA2350EA/2K5:
Novo em embalagem comercial
Garantia de OPA2350EA/2K5:
7 dias troca. Sem garantia após soldado
Outros PNs para este componente: OPA2350EA/2K5G4This part number is identical to the part number listed above. You can only order quantities of the part number listed above.
| Manufacturer: | Texas Instruments |
| Product Category: | High Speed Operational Amplifiers |
| RoHS: | |
| Series: | OPA2350 |
| Number of Channels: | 2 Channel |
| GBP Gain Bandwidth Product: | 38 MHz |
| SR Slew Rate: | 22 V/us |
| Voltage Gain dB: | 122 dB |
| CMRR Common Mode Rejection Ratio: | 90 dB |
| Output Current per Channel: | 40 mA |
| Ib Input Bias Current: | 10 pA |
| Vos Input Offset Voltage: | 150 uV |
| Supply Voltage Max: | 5.5 V |
| Supply Voltage Min: | 2.7 V |
| Operating Supply Current: | 5.2 mA |
| Minimum Operating Temperature: | 40 C |
| Maximum Operating Temperature: | 85 C |
| Mounting Style: | SMD/SMT |
| Package / Case: | VSSOP8 |
| Packaging: | Reel |
| Packaging: | Cut Tape |
| Packaging: | MouseReel |
| Brand: | Texas Instruments |
| en Input Voltage Noise Density: | 7 nV/sqrt Hz |
| Height: | 0.97 mm |
| Input Type: | RailtoRail |
| Length: | 3 mm |
| Moisture Sensitive: | Yes |
| Operating Supply Voltage: | 5.5 V |
Maiores detalhes de OPA2350EA/2K5 no site do fabricante:
https://www.ti.com/lit/ds/symlink/opa2350.pdf?ts=1679035351687eref_url=https%253
Tags de OPA2350EA/2K5: OPA2350EA/2K5, OPA2350EA, OPA2350, OPA2350E, D50 99M4, OPA2350EA/2K5G4This part number is identical to the part number listed above. You can only order quantities of the part number listed above, OPA350, OPA4350, MSOP8, Texas Instruments
