PCA9534DWR Interface I/O Expander Remote 8bit I2C low power

Name: PCA9534DWR Interface I/O Expander Remote 8bit I2C low power
Brand: Texas Instruments
SKU: PCA9534DWR
Price: 14.00 BRL
Availability: InStock

SSOP16 I/O Expander with Interrupt Output and Configuration Registers

clique para ampliar

*As imagens podem ser ilustrativas

em estoque, envio imediato

R$ 14,00

à vista no Pix ou Boleto

ou R$ 14,21 em 1x no cartão (via site)

ou R$ 15,00 no cartão em até 10x sem juros (apenas na loja física)

R$ 14,00

à vista no Pix ou Boleto

R$ 14,21
em 1x no cartão (via site)

R$ 15,00 no cartão
em até 10x sem juros
(apenas na loja física)

Comprar

Condição:

Novo em embalagem comercial

Garantia:

3 meses direto com a Net Computadores

NCM:

85423190

R$ 14,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
3 meses direto com a Net Computadores

NCM: 85423190

Comprar via
MERCADO LIVRE

Somos MercadoLivre Platinum
Comprar à Vista no MercadoLivre

Cotação PJ mais de uma unidade

Indicar PCA9534DWR

PCA9534DWR Interface I/O Expander Remote 8bit I2C low power
SSOP16 I/O Expander with Interrupt Output and Configuration Registers

Condição de PCA9534DWR: Novo em embalagem comercial

Garantia de PCA9534DWR: 3 meses direto com a Net Computadores

Features
- Low standby current consumption of 1 -A Max
- I2C to Parallel port expander
- Open-drain active-low interrupt output
- Operating power-supply voltage range of 2.3 V to 5.5 V
- 5-V Tolerant I/O ports
- 400-kHz Fast I2C bus
- Three hardware address pins allow up to eight devices on the I2C/SMBus
- Allows up to 16 devices on the I2C/SMBus when used in conjunction with the PCA9534A See Section 5 for I2C Expander offerings
- Input/output configuration register
- Polarity inversion register
- Internal power-on reset
- Power-up with all channels configured as inputs
- No glitch on power up
- Noise filter on SCL/SDA inputs
- Latched outputs with high-current drive maximum capability for directly driving LEDs
- Latch-up performance exceeds 100 mA Per JESD 78, class II
- ESD Protection exceeds JESD 22 - 2000-V Human-body model (A114-A) - 200-V Machine model (A115-A) - 1000-V Charged-device Model (C101)

Description
This 8-bit I/O expander for the two-line bidirectional bus (I2C) is designed for 2.3-V to 5.5-V VCC operation.
It provides general-purpose remote I/O expansion for most microcontroller families via the I2C interface [serial clock (SCL), serial data (SDA)].

The PCA9534 consists of one 8-bit Configuration (input or output selection), Input Port, Output Port, and Polarity Inversion (active high or active low) register.

At power on, the I/Os are configured as inputs. However, the system master can enable the I/Os as either inputs or outputs by writing to the I/O configuration bits.

The data for each input or output is kept in the corresponding Input or Output register.

The polarity of the Input Port register can be inverted with the Polarity Inversion register. All registers can be read by the system master. The system master can reset the PCA9534 in the event of a timeout or other improper operation by utilizing the power-on reset feature, which puts the registers in their default state and initializes the I2C/ SMBus state machine. The PCA9534 open-drain interrupt ( INT) output is activated when any input state differs from its corresponding input port register state and is used to indicate to the system master that an input state has changed.
