PWS-0055 Supermicro Fonte 1U 260w SP262-1S

PWS-0055 - SUPERMICRO
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
clique para ampliar
*As imagens podem ser ilustrativas
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S
PWS-0055 Supermicro Fonte 1U 260w SP262-1S

R$ 2.087,00

à vista no Pix ou Boleto

ou R$ 2.196,41 em 1x no cartão (via site)

ou R$ 2.318,43 no cartão em até 10x sem juros (apenas na loja física)

R$ 2.087,00

à vista no Pix ou Boleto

R$ 2.196,41
em 1x no cartão (via site)

R$ 2.318,43 no cartão
em até 10x sem juros
(apenas na loja física)

Garantia:
12 meses direto com a Net Computadores

NCM:
85043119

R$ 2.087,00

à vista no pix

Condição:
Novo em embalagem antiestática

Garantia:
12 meses direto com a Net Computadores

NCM: 85043119

PWS-0055 Supermicro Fonte 1U 260w SP262-1S

Condição de PWS-0055:    Novo em embalagem antiestática

Garantia  de  PWS-0055:     12 meses direto com a Net Computadores

Outros PNs para este item:     SP262-1S



The Supermicro PWS-0055 is capable of 260W output power at high efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages and a quiet fan to keep it cool under heavy loads. This power supply is designed to not only provide you reliable power to your 1U server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. All materials contained comply with RoHS requirements and are certified by Supermicro.

Cables Included:
  • 1x 24 Pin ATX (Motherboard)
  • 1x 4 Pin 12V (CPU)
  • 2x 4 Pin Legacy HDD
  • 2x 4 Pin Floppy/DVD Drive

Product Specifications
Product Name 260W Power Supply 1U SP262-1S
Product Type Proprietary Power Supply
Input Voltage Type AC
Input Voltage 240 V AC
Output Power 260 W
Receptacles 4-pin ATX
24-pin Motherboard
Input Voltage Range 100 V AC to 240 V AC

Compatibility
SuperServer 5014C-T
Output Voltage 5 V DC
12 V DC
-12 V DC
3.3 V DC

Additional Information
Power Supply Rack Height: 1U

Total Power Output 260W
Type Single
Type of Power Supply Power Supply
Form Factor 1U
Dimension (W x H x L) 84 x 40 x 220mm
5V 25A
12V 18A
3.3V 15A
5V Standby 2A
Input Voltage Range 100-240Vac
Input Frequency Range 50-60Hz
Input Current Range 5A Max
Output Type 24Pin ATX Cable Output
8Pin / 4Pin (12V) Connector 4pin
PFC Yes
Voltage / Current No
Energy Efficiency N/A
80 Plus Certification N/A
Validated Chassis CSE-512L-260-LCD

Tags de PWS-0055: CSE-512L-260-LCD, CSE-512L-260, CSE-512L260LCD, SP262-1S, SP2621S, SP262 1S, PWS-0055, PWS 0055, PWS0055, Fonte 260w, Fonte 1u 260w, Fonte para servidor, Fonte Redundante, Fonte DELL, Fonte HP, Fonte IBM, Fonte Proliant, Fonte Server, Fonte de Alimentação, Fonte de servidor, SUPERMICRO

PWS-0055 Supermicro Fonte 1U 260w SP262-1S

Condição de PWS-0055:
Novo em embalagem antiestática

Garantia  de  PWS-0055:
12 meses direto com a Net Computadores

Outros PNs para este componente:     SP262-1S


The Supermicro PWS-0055 is capable of 260W output power at high efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages and a quiet fan to keep it cool under heavy loads. This power supply is designed to not only provide you reliable power to your 1U server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. All materials contained comply with RoHS requirements and are certified by Supermicro.

Cables Included:
  • 1x 24 Pin ATX (Motherboard)
  • 1x 4 Pin 12V (CPU)
  • 2x 4 Pin Legacy HDD
  • 2x 4 Pin Floppy/DVD Drive

Product Specifications
Product Name 260W Power Supply 1U SP262-1S
Product Type Proprietary Power Supply
Input Voltage Type AC
Input Voltage 240 V AC
Output Power 260 W
Receptacles 4-pin ATX
24-pin Motherboard
Input Voltage Range 100 V AC to 240 V AC

Compatibility
SuperServer 5014C-T
Output Voltage 5 V DC
12 V DC
-12 V DC
3.3 V DC

Additional Information
Power Supply Rack Height: 1U

Total Power Output 260W
Type Single
Type of Power Supply Power Supply
Form Factor 1U
Dimension (W x H x L) 84 x 40 x 220mm
5V 25A
12V 18A
3.3V 15A
5V Standby 2A
Input Voltage Range 100-240Vac
Input Frequency Range 50-60Hz
Input Current Range 5A Max
Output Type 24Pin ATX Cable Output
8Pin / 4Pin (12V) Connector 4pin
PFC Yes
Voltage / Current No
Energy Efficiency N/A
80 Plus Certification N/A
Validated Chassis CSE-512L-260-LCD

Tags de PWS-0055: CSE-512L-260-LCD, CSE-512L-260, CSE-512L260LCD, SP262-1S, SP2621S, SP262 1S, PWS-0055, PWS 0055, PWS0055, Fonte 260w, Fonte 1u 260w, Fonte para servidor, Fonte Redundante, Fonte DELL, Fonte HP, Fonte IBM, Fonte Proliant, Fonte Server, Fonte de Alimentação, Fonte de servidor, SUPERMICRO
