SR20969-C0 Chassis Server Workstation Chenbro ATX

(Backplane de 4 Baias 3.5Pol. Hot Swap Opcional - PN: 84H220910-079)

SR20969-C0 Chassis Server Workstation Chenbro ATX

*As imagens podem ser ilustrativas

avise-me quando disponível

R$ 427,00

à vista no Pix ou Boleto

ou R$ 449,34 em 1x no cartão (via site)

ou R$ 474,31 no cartão em até 10x sem juros (apenas na loja física)

R$ 427,00

à vista no Pix ou Boleto

R$ 449,34
em 1x no cartão (via site)

R$ 474,31 no cartão
em até 10x sem juros
(apenas na loja física)

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

84733019

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 84733019

Cotação PJ mais de uma unidade

Indicar SR20969-C0

SR20969-C0 Chassis Server Workstation Chenbro ATX
(Backplane de 4 Baias 3.5Pol. Hot Swap Opcional - PN: 84H220910-079)

Condição de SR20969-C0: Novo em embalagem comercial

Garantia de SR20969-C0: 12 meses direto com a Net Computadores

Specification
Order Code
SR20969-C0
Description
SR20969H02*6671 Chassis Only w/o HDD Cage w/o power (BK)
M/B Form Factor
ATX (12"x9.6")
Processor
Intel / AMD UP Quad
Support Backplane
3.5" / 2.5" Mini-SAS
SATA II/SAS
Security
Intrusion Switch
Kensington Lock Supported
Front Bezel Option
Optional
Chassis Dimension
D x W x H (mm) 465 x 198 x 425 (mm)
D x W x H (inch) 18.3" x 7.8" x 16.7"
Power Supply
Form Factor PS/2
Watt PS2,ATX
Drive Bay
Hot-Swap 3.5" 4
Hot-Swap 2.5" 6
External 5.25" 3
External 3.5" 1
Internal 3.5" -
Internal 2.5" -
Slim ODD -
Slim FDD -

Generality
Metal Material SECC
Metal Thickness 0.8 mm
Plastic Material Type ABS-HB
Expansion Slots
FF 5
FH 2
System Cooling
Front 1 x 92 mm (Optional), 1 x 80 mm or 92 mm (For HDD)
Rear 1 x 120mm PWM
Front Panel
Front Control Power On/Off
System Reset
Alarm Mute
USB 2.0 (x2)

Indicator Power Status LED(x1)
HDD Activity LED(x1)
LAN Activity LED(x2)

Package Contain
Part Category Qty. Description
Fans 1 ADDA, 120mm = T25 + L650MM(PWM), 2500RPM with finger guard, Rear Fan
Cables 1 Cable SW. (power,reset,alarm mute ) 550mm/350mm
1 Intrusion Switch cable, 2P2C, 800mm
1 CABLE,USB 2.0,SR10569e12,700MM, FOR INTEL SPEC.
1 Cable LED Display,550mm
Slide Rail 6 CD-ROM Slide Rails w/holder box
EMI LINER 1 200mm EMI liner for back edge
1 445mm EMI Liner for bottom edge
Foot Stand 1 Foot Stand (BK)
Front Bezel 1 SR20969 Front Bezel (BK)
Holder 1 120mm Rear Fan Holder
1 PCI Fan Plastic Holder For Front Fan
Key Lock 1 Metal Key Lock (on rear panel)
Packing 1 Single Packing Carton w/Chenbro logo
Optional Accessory
HDD Cage
Product Part. No# Description
84H220910-078 Hot Swap 3.5" HDD Cage w/MiniSAS 6G BP & 80mm Fan (BP#80H10220918A0)

84H220910-079 HDD Cage, 3.5" 4-Bay, w/6Gb/s SATA BP& 80mm Fan, SR105/209 (BP#80H10220919A0)

PSU
Product Part. No# Description
PS-SS-400ES PSU,PS-SS400ES,SIDE(80mm)FAN,80+ (brown),24+8+8(4+4)+3SATA
PS-SS-600ES PSU,600W,ATX,80+ Brown 24+8+6+4+3SATA

Server Front Bezel
Product Part. No# Description
86H220968-101 SR105/20968(Granite) Front Bezel (BK)
86H220969-201 SR105/20969 Front Bezel(GY)

Storage Kits
Product Part. No# Description
SK31101T2 STORAGE KIT, 5.25" TO 3.5" 6G HOTSWAP, CONVERTER (BK)
SK41101-BK-H STORAGE KIT, 5.25" TO 3.5" CONVERTER(BK), (bulk packing : 48pcs / box)
SK41202H01 Internal 5.25" to Slim DVD + 3.5" HDD / FDD Enclosure

Others
Product Part. No# Description
84H210710-047 12cm Fan Air Duct for Bensley Platform Soluton (bulk packing : 48pcs / box)

Maiores detalhes de SR20969-C0 no site do fabricante:
http://usa.chenbro.com/corporatesite/products_detail.php?sku=92

Tags de SR20969-C0: 84H220910-079, SR105, SR209, 84H220910-084, SR20969-C0, SR20969, Gabinete Server, Gabinete Servidor, Chassis Rack, Gabinete de Servidor, Chassis de Servidor, Gabinete para Servidor, Chassis Server, Chenbro
