Fontes de Alimentação / Fonte para Servidores / Não Redundante / 1U / TGC-SG1U400S

Fontes de Alimentação / Fonte para Servidores

TGC-SG1U400S TGC Fonte 1U 350W Reais 80 Plus

Medidas 200mm x 100mm x 40.5mm

TGC-SG1U400S TGC Fonte 1U 350W Reais 80 Plus

*As imagens podem ser ilustrativas

avise-me quando disponível

R$ 498,00

à vista no Pix ou Boleto

ou R$ 523,63 em 1x no cartão (via site)

ou R$ 552,72 no cartão em até 10x sem juros (apenas na loja física)

R$ 498,00

à vista no Pix ou Boleto

R$ 523,63
em 1x no cartão (via site)

R$ 552,72 no cartão
em até 10x sem juros
(apenas na loja física)

Condição:

Novo em embalagem comercial

Garantia:

3 meses direto com a Net Computadores

NCM:

84733099

Condição:
Novo em embalagem comercial

Garantia:
3 meses direto com a Net Computadores

NCM: 84733099

Cotação PJ mais de uma unidade

Indicar TGC-SG1U400S

TGC-SG1U400S TGC Fonte 1U 350W Reais 80 Plus
Medidas 200mm x 100mm x 40.5mm

Condição de TGC-SG1U400S: Novo em embalagem comercial

Garantia de TGC-SG1U400S: 3 meses direto com a Net Computadores

Features:
In accordance with IPC 1U specifications
Rated 350W, peak 400W
low noise, low ripple, high efficiency (minimum 78%)
by O ~ 50°C ambient temperature test
Product size: 200mm x 100mm x 40.5mm
Double fan: 4020mm dual ball mute fan
Life cycle: ≥ 100KH hours
Complete protection function: over current, over voltage, under voltage, over power, short-circuit protection
The certification: CE, FCC

Output interface:
20+4Pin 4+4Pin 5 Pin Big 4 Pin
Main power supply interface CPU interface SATA interface Peripheral equipment interface
1 1 3 3
Specifications:
Model No TGC-SG1U400
Total wattage output 350W
Efficiency > 78 % when full load
P. G Signal 100-500 ms
Hold-up Time 16ms minimum
Net Weight 1.5 KG
The appearance color metallic silver(natural metallic)
Fan size Ball-bearing 4020*2
dimension 200mm (L) x 100mm(W) x 40.5mm(H)
Protection Over current protection, over voltage protection, under voltage protection, over power protection, short circuit protection
Input characteristics
Input voltage range 180-264Vac
Input voltage frequency 47 ~ 63 Hz
Life cycle(MTBF) 100,000 hrs minimum (at 25 ?)
Input current 4A at 220-230V

Output characteristics
Voltage +5V +12V -12V +3.3V +5Vsb
MIN 1 0.5 0 0.5 0
NOM 8 11 0.25 9 1
MAX 16 22 0.5 18 2
Units AMPS AMPS AMPS AMPS AMPS
1) the total output power must not exceed 300W
2) +5V and +3.3V total output power must not exceed 120W
3) +5V, +3.3V, +12V total output power must not exceed 285W
Working environment
Working temperature 0 °C to 50 °C
Storage temperature -40 °C to 80°C
Operating humidity 20% to 85%, non-condensing
Storage temperature 10% to 95%, non-condensing

Maiores detalhes de TGC-SG1U400S no site do fabricante:
http://www.tgcipc.com/pt/product.php?mod=detail&id=42
