VCC-6584DN Camera SANYO VCC6584DN 1/3 CCD Super High Resolution DSP Day/Nigh

TTL auto tracing white-balance system, DC type auto iris lenses applicable, Built-in DSP (digital s

VCC-6584DN Camera SANYO VCC6584DN 1/3 CCD Super High Resolution DSP Day/Nigh

*As imagens podem ser ilustrativas

Camera SANYO VCC6584DN 1/3 CCD Super High Resolution DSP Day/Nigh

envio de 30 a 60 dias uteis

R$ 2.939,00

à vista no Pix ou Boleto

ou R$ 3.093,50 em 1x no cartão (via site)

ou R$ 3.265,36 no cartão em até 10x sem juros (apenas na loja física)

R$ 2.939,00

à vista no Pix ou Boleto

R$ 3.093,50
em 1x no cartão (via site)

R$ 3.265,36 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo em embalagem comercial

Garantia:

12 meses direto com a Net Computadores

NCM:

R$ 2.939,00

à vista no pix

Comprar

Condição:
Novo em embalagem comercial

Garantia:
12 meses direto com a Net Computadores

NCM: 0

Cotação PJ mais de uma unidade

Indicar VCC-6584DN

VCC-6584DN Camera SANYO VCC6584DN 1/3 CCD Super High Resolution DSP Day/Nigh
TTL auto tracing white-balance system, DC type auto iris lenses applicable, Built-in DSP (digital s

Condição de VCC-6584DN: Novo em embalagem comercial

Garantia de VCC-6584DN: 12 meses direto com a Net Computadores

The VCC6584DN from SANYO has maximum sensitivity which is significantly increased by about 6dB compared to conventional models. A newly-developed CCD sensor partners with SANYO’s advanced technologies to enable the camera to clearly capture objects even in dark conditions. The VCC6584DN is a 1/3" CCD Super High Resolution DSP Day/Night Color Camera that has high resolution of 540 TV Lines ,min.

Illumination of 0.35/0.25 Lux @ F1.2 lens at high gain and compensation of 64 Section BLC, dual power supply of 12/24 dc voltage. The VCC6584DN has high sensitivity which is significantly increased by about 6dB compared to conventional models. There are two systems for luminance measurement that are Multi-spot photometry system – in this system luminance is measured in 64 separate areas for optimum backlight compensation even for peripheral and moving objects. Features selectable normal and high modes.

Centre-zone photometry system - in this system luminance is measured at centre and automatic lens aperture adjustment enable a clear image even when backlit. The VCC6584DN is a new E-Day/Night function that allows an automatic changeover from color mode to B/W mode which makes it possible to achieve 24-hour high-quality in light and dark conditions.

Features

TTL auto tracing white-balance system.

Equipped with electronic iris (indoor use).

Internal / Line-Lock synchronization system.

DC type auto iris lenses applicable.

1/3-inch CCD image sensor with approx. 410,000 picture elements.

High horizontal resolution of 540 TV (typical) lines for maximum details and a noticeably sharper, clearer picture.

E-Day/Night function (Electronic Day/Night).

High sensitivity for monitoring.

Excellent immunity to shock and vibration using all solid-state components.

Accurate color is achieved by processing image data through a color complementary Ye-Cy-Mg-G mosaic filter.

Built-in DSP (digital signal processing) circuitry delivers superior color reproduction and reduced noise.

Two types of backlight compensation selectable.

Specifications	Value
Scanning system	NTSC Standard 525 lines, 30 frames/sec
Image sensor	1/3” (approx. 4.8 x 3.6 mm) interline transfer method CCD
Effective picture elements	768 (H) x 494 (V)
Horizontal resolution	540 TV lines (typical
Minimum illumination (approx.)	20IRE - 0.14 lx (at F1.2, GAIN: HI, color mode), 0.1 lx (at F1.2, GAIN: HI, B/W mode) 50IRE - 0.35 lx (at F1.2, GAIN: HI, color mode), 0.25 lx (at F1.2, GAIN: HI, B/W mode)
Video output level	1.0 V (p-p) / 75 ohms, composite
Video S/N ratio	More than 50 dB (AGC off)
Backlight compensation	ON / OFF — Slide SW (side) ON = Multi-spot photometry (64-section) / Center-zone photometry system — Slide SW (side) (activated when auto iris lens used)
White balance	Auto / Manual — Slide SW (side)
Gain control	Normal / High — Slide SW (side)
Light control	Auto iris / Electronic iris
Lens mount	CS mount (top/bottom selectable)
Flange back	12.5 mm ±0.5 mm adjustment
Auto iris lens	DC type
Auto iris output	DC: Drive coil (+, –), Brake (Damp) coil (+, –)
Lens iris level	LEVEL: L to H — VR (side)
Electronic iris	ON (EI) / OFF (AI) — Slide SW (side)
Electronic iris range	0.35 to 50,000 lx (with F1.2 lens) GAIN HIGH (Color mode) 0.35 to 50,000 lx (with F1.2 lens) GAIN HIGH (B/W mode)
Synchronizing system	Internal sync / Line lock — Slide SW (side)
V phase adjustment	LINE PHASE — VR (rear)
Sockets	Video signal - VIDEO OUT — BNC (rear) Auto iris lens - LENS — 4-pin (side) Power supply - 24V AC, GND — 3-pin terminal (rear) 12V DC, GND — 2-pin terminal (rear)
Operating conditions	Operating - Temperature: –10°C to 50°C (14°F to 122°F), Humidity: within 90% RH Storage - Temperature: –20°C to 70°C (–4°F to 158°F), Humidity: within 70% RH
Power requirement	24V AC, 60 Hz / 12 to 15V DC
Power consumption (approx.)	3.6 W
Camera mount	1/4” – 20 UNC (top/bottom selectable)
Dimensions (approx.)	56 (W) x 45 (H) x 99 (D) mm [2.21 (W) x 1.77 (H) x 3.9 (D) in.] (excluding protrusions)
Weight (approx.)	260 g [9.17 oz] (without lens)

Tags de VCC-6584DN: Camera de segurança, auto iris, CCD, DSP, SANYO

VCC-6584DN Camera SANYO VCC6584DN 1/3 CCD Super High Resolution DSP Day/Nigh TTL auto tracing white-balance system, DC type auto iris lenses applicable, Built-in DSP (digital s

Condição de VCC-6584DN:
Novo em embalagem comercial

Garantia de VCC-6584DN:
12 meses direto com a Net Computadores

The VCC6584DN from SANYO has maximum sensitivity which is significantly increased by about 6dB compared to conventional models. A newly-developed CCD sensor partners with SANYO’s advanced technologies to enable the camera to clearly capture objects even in dark conditions. The VCC6584DN is a 1/3" CCD Super High Resolution DSP Day/Night Color Camera that has high resolution of 540 TV Lines ,min.

Illumination of 0.35/0.25 Lux @ F1.2 lens at high gain and compensation of 64 Section BLC, dual power supply of 12/24 dc voltage. The VCC6584DN has high sensitivity which is significantly increased by about 6dB compared to conventional models. There are two systems for luminance measurement that are Multi-spot photometry system – in this system luminance is measured in 64 separate areas for optimum backlight compensation even for peripheral and moving objects. Features selectable normal and high modes.

Centre-zone photometry system - in this system luminance is measured at centre and automatic lens aperture adjustment enable a clear image even when backlit. The VCC6584DN is a new E-Day/Night that allows an automatic changeover from color mode to B/W mode which makes it possible to achieve 24-hour high-quality in light and dark conditions.

Features

TTL auto tracing white-balance system.

Equipped with electronic iris (indoor use).

Internal / Line-Lock synchronization system.

DC type auto iris lenses applicable.

1/3-inch CCD image sensor with approx. 410,000 picture elements.

High horizontal resolution of 540 TV (typical) lines for maximum details and a noticeably sharper, clearer picture.

E-Day/Night (Electronic Day/Night).

High sensitivity for monitoring.

Excellent immunity to shock and vibration using all solid-state components.

Accurate color is achieved by processing image data through a color complementary Ye-Cy-Mg-G mosaic filter.

Built-in DSP (digital signal processing) circuitry delivers superior color reproduction and reduced noise.

Two types of backlight compensation selectable.

Specifications	Value
Scanning system	NTSC Standard 525 lines, 30 frames/sec
Image sensor	1/3” (approx. 4.8 x 3.6 mm) interline transfer method CCD
Effective picture elements	768 (H) x 494 (V)
Horizontal resolution	540 TV lines (typical
Minimum illumination (approx.)	20IRE - 0.14 lx (at F1.2, GAIN: HI, color mode), 0.1 lx (at F1.2, GAIN: HI, B/W mode) 50IRE - 0.35 lx (at F1.2, GAIN: HI, color mode), 0.25 lx (at F1.2, GAIN: HI, B/W mode)
Video output level	1.0 V (p-p) / 75 ohms, composite
Video S/N ratio	More than 50 dB (AGC off)
Backlight compensation	ON / OFF — Slide SW (side) ON = Multi-spot photometry (64-section) / Center-zone photometry system — Slide SW (side) (activated when auto iris lens used)
White balance	Auto / Manual — Slide SW (side)
Gain control	Normal / High — Slide SW (side)
Light control	Auto iris / Electronic iris
Lens mount	CS mount (top/bottom selectable)
Flange back	12.5 mm ±0.5 mm adjustment
Auto iris lens	DC type
Auto iris output	DC: Drive coil (+, –), Brake (Damp) coil (+, –)
Lens iris level	LEVEL: L to H — VR (side)
Electronic iris	ON (EI) / OFF (AI) — Slide SW (side)
Electronic iris range	0.35 to 50,000 lx (with F1.2 lens) GAIN HIGH (Color mode) 0.35 to 50,000 lx (with F1.2 lens) GAIN HIGH (B/W mode)
Synchronizing system	Internal sync / Line lock — Slide SW (side)
V phase adjustment	LINE PHASE — VR (rear)
Sockets	Video signal - VIDEO OUT — BNC (rear) Auto iris lens - LENS — 4-pin (side) Power supply - 24V AC, GND — 3-pin terminal (rear) 12V DC, GND — 2-pin terminal (rear)
Operating conditions	Operating - Temperature: –10°C to 50°C (14°F to 122°F), Humidity: within 90% RH Storage - Temperature: –20°C to 70°C (–4°F to 158°F), Humidity: within 70% RH
Power requirement	24V AC, 60 Hz / 12 to 15V DC
Power consumption (approx.)	3.6 W
Camera mount	1/4” – 20 UNC (top/bottom selectable)
Dimensions (approx.)	56 (W) x 45 (H) x 99 (D) mm [2.21 (W) x 1.77 (H) x 3.9 (D) in.] (excluding protrusions)
Weight (approx.)	260 g [9.17 oz] (without lens)
