Placas Mãe / Server Board Xeon / LGA 2011 V4 / X10SRM-F

Placas Mãe / Server Board Xeon

X10SRM-F Supermicro Mainboard Intel E5-2600 V3 V4

Name: X10SRM-F Supermicro Mainboard Intel E5-2600 V3 V4
Brand: SUPERMICRO
SKU: X10SRM-F
Price: 5553.00 BRL
Availability: InStock

Socket R3 LGA2011 C612 chipset, DDR4 512GB até 2400Mhz, 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, Dual GbE L

clique para ampliar

*As imagens podem ser ilustrativas

envio de 30 a 60 dias uteis

R$ 5.553,00

à vista no Pix ou Boleto

ou R$ 5.845,08 em 1x no cartão (via site)

ou R$ 6.169,80 no cartão em até 10x sem juros (apenas na loja física)

R$ 5.553,00

à vista no Pix ou Boleto

R$ 5.845,08
em 1x no cartão (via site)

R$ 6.169,80 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo recondicionado grade B - Pronto para uso!

Garantia:

6 meses direto com a Net Computadores

NCM:

84733041

R$ 5.553,00

à vista no pix

Comprar

Condição:
Novo recondicionado grade B - Pronto para uso!

Garantia:
6 meses direto com a Net Computadores

NCM: 84733041

Cotação PJ mais de uma unidade

Indicar X10SRM-F

X10SRM-F Supermicro Mainboard Intel E5-2600 V3 V4
Socket R3 LGA2011 C612 chipset, DDR4 512GB até 2400Mhz, 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, Dual GbE L

Condição de X10SRM-F: Novo recondicionado grade B - Pronto para uso!

Garantia de X10SRM-F: 6 meses direto com a Net Computadores

Motherboard MicroATX Intel C612 Chipset Socket R3 (LGA 2011) for Single Intel Xeon E5-2600 v3 / 1600 v3 family processors
- Supports up to 256GB DDR4 ECC LRDIMM (4x 288-pin sockets)
- On-board: SATA3 (6Gbps) via C612 controller (RAID 0 / 1 / 10 support), IPMI 2.0, 2x Gigabit Ethernet, VGA
- MBD-X10SRM-F-O (Retail Box)

Key Features:
- 0°~60°C (board level) Operation
Temperature
- 7-year lifespan
- Support 12V only power supply
- Two 4-pin internal power (output)
connectors
- One M.2 connector to support
22110, 2280 and 2242 modules

1. Single socket R3 (LGA 2011) supports
Intel Xeon processor E5-2600
v4-/ v3 and E5-1600 v4-/ v3 family
2. Intel® C612 chipset
3. Up to 512GB- ECC 3DS LRDIMM , up to
DDR4- 2400-MHz ; 4x DIMM slots
4. 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x8
5. Intel® i350 Dual GbE LAN ports
6. 10x SATA3 (6Gbps) via C612
7. 1x VGA, 2x COM, 1x TPM
8. 5x USB 3.0 ports, 6x USB 2.0 ports
9. 2x SuperDOM with built-in power

Product SKUs

MBD-X10SRM-F -B	X10SRM-F (Bulk Pack)


Physical Stats

Form Factor	Micro ATX
Dimensions	9.6 x 9.6, (24.4cm x 24.4cm)


Processor

CPU	Intel® Xeon® processor E5-2600 v4-/ v3, E5-1600 v4-/ v3 family (up to 145W TDP **) Single Socket R3 (LGA 2011)
Core / Cache	Up to 22 Cores- / Up to 55MB- Cache
Note	- BIOS version 2.0 or above is required
Note	** Motherboard supports this maximum TDP. Please verify your system can thermally support


System Memory

Memory Capacity	4x 288-pin DDR4 DIMM slots Up to 512GB ECC 3DS LRDIMM Up to 256GB ECC LRDIMM Up to 128GB ECC RDIMM
Memory Type	2400-/ 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (RDIMM / LRDIMM) / 284-pin gold-plated DIMMs
DIMM Sizes	3DS LRDIMM: 128GB LRDIMM: 64GB, 32GB RDIMM: 32GB, 16GB, 8GB, 4GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)


On-Board Devices

Chipset	Intel C612 chipset
SATA	SATA3 (6Gbps) via C612 controller RAID 0, 1, 10 support
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC
Network Controllers	Dual LAN with Intel® i350 Gigabit Ethernet Controller Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Graphics	ASPEED AST2400 BMC


Input / Output

SATA	10x SATA3 (6Gbps) ports
LAN	2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port
USB	5x USB 3.0 ports (2 rear 2 via header 1 Type A) 6x USB 2.0 ports (2 rear 4 via header)
Video	1x VGA port
Serial Port / Header	2x COM ports (1 rear, 1 header)
SuperDOM	2x SuperDOM (Disk on Module) ports with built-in power
TPM	1x TPM Header

Maiores detalhes de X10SRM-F no site do fabricante:
https://www.supermicro.com/products/motherboard/Xeon/C600/X10SRM-F.cfm

Tags de X10SRM-F: X10SRM-F, X10SRMF, MBD-X10SRM-F-O, X10SRM F, SUPERMICRO

X10SRM-F Supermicro Mainboard Intel E5-2600 V3 V4 Socket R3 LGA2011 C612 chipset, DDR4 512GB até 2400Mhz, 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, Dual GbE L

Condição de X10SRM-F:
Novo recondicionado grade B - Pronto para uso!

Garantia de X10SRM-F:
6 meses direto com a Net Computadores

Product SKUs

MBD-X10SRM-F -B	X10SRM-F (Bulk Pack)


Physical Stats

Form Factor	Micro ATX
Dimensions	9.6 x 9.6, (24.4cm x 24.4cm)


Processor

CPU	Intel® Xeon® processor E5-2600 v4-/ v3, E5-1600 v4-/ v3 family (up to 145W TDP **) Single Socket R3 (LGA 2011)
Core / Cache	Up to 22 Cores- / Up to 55MB- Cache
Note	- BIOS version 2.0 or above is required
Note	** Motherboard supports this maximum TDP. Please verify your system can thermally support


System Memory

Memory Capacity	4x 288-pin DDR4 DIMM slots Up to 512GB ECC 3DS LRDIMM Up to 256GB ECC LRDIMM Up to 128GB ECC RDIMM
Memory Type	2400-/ 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (RDIMM / LRDIMM) / 284-pin gold-plated DIMMs
DIMM Sizes	3DS LRDIMM: 128GB LRDIMM: 64GB, 32GB RDIMM: 32GB, 16GB, 8GB, 4GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)


On-Board Devices

Chipset	Intel C612 chipset
SATA	SATA3 (6Gbps) via C612 controller RAID 0, 1, 10 support
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC
Network Controllers	Dual LAN with Intel® i350 Gigabit Ethernet Controller Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Graphics	ASPEED AST2400 BMC


Input / Output

SATA	10x SATA3 (6Gbps) ports
LAN	2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port
USB	5x USB 3.0 ports (2 rear 2 via header 1 Type A) 6x USB 2.0 ports (2 rear 4 via header)
Video	1x VGA port
Serial Port / Header	2x COM ports (1 rear, 1 header)
SuperDOM	2x SuperDOM (Disk on Module) ports with built-in power
TPM	1x TPM Header
