Componentes Eletrônicos / Semicondutores / LMC555CMM

LMC555CMM

CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP

Worlds smallest 555 timer with low power, high accuracy and a Fmax of 3MHz 8-VSSOP -40 to 85

LMC555CMM - National Semiconductor
LMC555CMM CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP
CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOPCI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOPCI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOPCI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP
*Imagens ilustrativas

LMC555CMM

CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP

Worlds smallest 555 timer with low power, high accuracy and a Fmax of 3MHz 8-VSSOP -40 to 85

Garantia:
3 meses direto com a Net Computadores

NCM:
85423190

avise-me quando disponível

R$ 1,50

À vista já com 5% de desconto (boleto/pix). Preço base SP. Informaremos caso incidam impostos interestaduais.

ou no cartão de crédito por R$ 1,58

Condição exclusiva para o site. Parcelas serão exibidas na tela de pagamento.

R$ 1,50

À vista já com 10% de desconto (boleto/pix). Preço base SP. Informaremos caso incidam impostos interestaduais.

ou R$ 1,67 no cartão de crédito em até 10x sem juros

Condição exclusiva para compras presenciais na loja física.

R$ 1,50

à vista no pix

Condição: novo em embalagem comercial

Garantia: 3 meses direto com a Net Computadores

NCM: 85423190


LMC555CMM CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP

Condição de LMC555CMM: novo em embalagem comercial


Outros Part Numbers para este componente: LMC555CMM/NOPB

Series: LMC555
Type: Standard
Number of Internal Timers: 1 Timer
Supply Voltage - Max: 15 V
Supply Voltage - Min: 1.5 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: 125 C
Mounting Style: SMD/SMT
Package / Case: VSSOP-8
Packaging: Cut Tape
Packaging: MouseReel
Packaging: Reel
Height: 0.86 mm
Length: 3 mm
Width: 3 mm
Brand: National Semiconductor
Propagation Delay - Max: 100 ns (Typ) at 5 V
High Level Output Current: 50 mA
Low Level Output Current: - 10 mA
Operating Supply Current: 50 uA
Pd - Power Dissipation: 555 mW
Product Type: Timers e Support Products

LMC555CMM CI Timer LMC555 Socket Micro SMD 8VSSOP 8MSOP


Condição de LMC555CMM: novo em embalagem comercial

Tags de LMC555CMM: LMC555CMM, LMC555CMM/N0PB, LMC555CMMCT/ND, 8-VSSOP, VSSOP-8, NE555, LM555, Mini LM555, Micro LM555, Micro NE555, Mini NE555, Ci 555, NE555-SMD, National Semiconductor, National Semiconductor
