LSI00211 Controladora LSI Megaraid SAS 9280-24i4E

24 Canais (6x SFF-8087 1x SFF-8088 6GBs) SATA+SAS 512MB - PCI Express 2.0 x8

LSI00211 Controladora LSI Megaraid SAS 9280-24i4E

*As imagens podem ser ilustrativas

Controladora LSI Megaraid SAS 9280-24i4E

envio de 30 a 60 dias uteis

R$ 2.475,00

à vista no Pix ou Boleto

ou R$ 2.605,13 em 1x no cartão (via site)

ou R$ 2.749,86 no cartão em até 10x sem juros (apenas na loja física)

R$ 2.475,00

à vista no Pix ou Boleto

R$ 2.605,13
em 1x no cartão (via site)

R$ 2.749,86 no cartão
em até 10x sem juros
(apenas na loja física)

Preço e prazo desatualizados, solicite revisão antes de comprar

Comprar

Preço e prazo desatualizados, solicite revisão antes de comprar

Condição:

Novo em embalagem antiestática

Garantia:

12 meses direto com a Net Computadores

NCM:

84733049

R$ 2.475,00

à vista no pix

Comprar

Condição:
Novo em embalagem antiestática

Garantia:
12 meses direto com a Net Computadores

NCM: 84733049

Cotação PJ mais de uma unidade

Indicar LSI00211

LSI00211 Controladora LSI Megaraid SAS 9280-24i4E
24 Canais (6x SFF-8087 1x SFF-8088 6GBs) SATA+SAS 512MB - PCI Express 2.0 x8

Condição de LSI00211: Novo em embalagem antiestática

Garantia de LSI00211: 12 meses direto com a Net Computadores

The 6Gb/s MegaRAID SAS 9280-24i4e, with twenty-four internal and four external ports, supports both internal drive storage and external JBOD expansion for up to 240 SATA or SAS drives. With a large number of internal ports, the 9280-24i4e connects up to 24 drives inside the server via direct connection or passive backplane. Using the external SAS ports, multiple JBODs can be connected to a server, providing a scalable and affordable solution for growing storage requirements.
24-Port Internal / 4-Port External PCI Express SATA and SAS RAID Controller

MegaRAID SAS 9280-24i4e Features

Twenty-Eight 6Gb/s SATA SAS ports
Six Mini-SAS internal connectors
One Mini-SAS external connector (SFF-8088)
LSISAS2108 6Gb/s RAID-on-Chip
- 800MHz PowerPC
512MB 800MHz DDRII cache memory
Optional battery backup module (Remote mount only)
RAID Levels 0, 1, 5 and 6
RAID Spans 10, 50 and 60
Internal drive storage and external JBOD expansion
PCI Express 2.0 provides faster signaling for high-bandwidth applications
Connect up to 240 3Gb/s and 6Gb/s SATA and SAS devices
Support for LSI Advanced Software options including FastPath, CacheCade, SafeStore, and Recovery

Solution Provided	Twenty-four-port internal / Four-port external SATA SAS solution for internal drive storage and external JBOD expansion using up to 240 SAS and/or SATA devices
Physical Dimensions	Half-Length, Full Height (6.6- x 4.376-)
Internal Connectors	Six Mini-SAS SFF8087 4i internal connectors
External Connectors	One Mini-SAS SFF8088 4x external connector
Device Support	Up to 240 SAS and/or SATA devices
Host Bus Type	x8 lane PCI Express 2.0 Compliant
Data Transfer Rates	Up to 6Gb/s per port
I/O Processor/SAS Controller	LSISAS2108 RAID on Chip (ROC) and LSISAS2x36 Expander
Cache Memory	512MB 800MHz DDR II SDRAM
Key RAID Data Protection Features	RAID levels 0, 1, 5, and 6 RAID spans 10, 50 and 60 Online Capacity Expansion (OCE) Online RAID Level Migration (RLM) Auto resume after loss of system power during array rebuild or reconstruction (RLM) Single controller Multipathing Load Balancing Configurable stripe size up to 1MB Fast initialization for quick array setup Check Consistency for background data integrity Support for Advanced Software options including FastPath, CacheCade, SafeStore, and Recovery SSD Support with SSD Guard-	Patrol read for media scanning and repairing 64 logical drive support Up to 64TB LUN support DDF compliant Configuration on Disk (COD) S.M.A.R.T support Global and dedicated Hot Spare with Revertible Hot Spare support - Automatic rebuild - Enclosure affinity - Emergency SATA hot spare for SAS arrays Enclosure management - SES (inband) - SGPIO (sideband)
Operating Temperature	Maximum ambient: 60C (45C w/iBBU)
Operating Voltage	3.3V
Regulatory Certifications	EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC; BSMI; C-tick
RAID Management	MegaRAID Management Suite -MegaRAID Storage Manager -MegaCLI (command-line interface) -WebBIOS
OS Support	Extensive support includes Microsoft Windows Vista/2008/Server 2003/2000/XP, Linux, Solaris- (x86), Netware, FreeBSD, VMware and more. Visit the LSI download Center for the most complete list of supported operating systems: lsi.com/channel/support

Tags de LSI00211: LSISAS2108, LSISAS2x36, 9280-24i4e, 16 canais, 16 HDs, 16 Channel, controladora para 16 HDs, LSI00211, 20 canais, 24 canais, Controladora RAID, Controladora SAS, Controladora SATA, Controladora de Backup, Placa Controladora, LSI Logic, 9280-24i4E, 928024i4E, LSI Logic

LSI00211 Controladora LSI Megaraid SAS 9280-24i4E 24 Canais (6x SFF-8087 1x SFF-8088 6GBs) SATA+SAS 512MB - PCI Express 2.0 x8

Condição de LSI00211:
Novo em embalagem antiestática

Garantia de LSI00211:
12 meses direto com a Net Computadores

Twenty-Eight 6Gb/s SATA SAS ports
Six Mini-SAS internal connectors
One Mini-SAS external connector (SFF-8088)
LSISAS2108 6Gb/s RAID-on-Chip
- 800MHz PowerPC
512MB 800MHz DDRII cache memory
Optional battery backup module (Remote mount only)
RAID Levels 0, 1, 5 and 6
RAID Spans 10, 50 and 60
Internal drive storage and external JBOD expansion
PCI Express 2.0 provides faster signaling for high-bandwidth applications
Connect up to 240 3Gb/s and 6Gb/s SATA and SAS devices
Support for LSI Advanced Software options including FastPath, CacheCade, SafeStore, and Recovery

Solution Provided	Twenty-four-port internal / Four-port external SATA SAS solution for internal drive storage and external JBOD expansion using up to 240 SAS and/or SATA devices
Physical Dimensions	Half-Length, Full Height (6.6- x 4.376-)
Internal Connectors	Six Mini-SAS SFF8087 4i internal connectors
External Connectors	One Mini-SAS SFF8088 4x external connector
Device Support	Up to 240 SAS and/or SATA devices
Host Bus Type	x8 lane PCI Express 2.0 Compliant
Data Transfer Rates	Up to 6Gb/s per port
I/O Processor/SAS Controller	LSISAS2108 RAID on Chip (ROC) and LSISAS2x36 Expander
Cache Memory	512MB 800MHz DDR II SDRAM
Key RAID Data Protection Features	RAID levels 0, 1, 5, and 6 RAID spans 10, 50 and 60 Online Capacity Expansion (OCE) Online RAID Level Migration (RLM) Auto resume after loss of system power during array rebuild or reconstruction (RLM) Single controller Multipathing Load Balancing Configurable stripe size up to 1MB Fast initialization for quick array setup Check Consistency for background data integrity Support for Advanced Software options including FastPath, CacheCade, SafeStore, and Recovery SSD Support with SSD Guard-	Patrol read for media scanning and repairing 64 logical drive support Up to 64TB LUN support DDF compliant Configuration on Disk (COD) S.M.A.R.T support Global and dedicated Hot Spare with Revertible Hot Spare support - Automatic rebuild - Enclosure affinity - Emergency SATA hot spare for SAS arrays Enclosure management - SES (inband) - SGPIO (sideband)
Operating Temperature	Maximum ambient: 60C (45C w/iBBU)
Operating Voltage	3.3V
Regulatory Certifications	EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC; BSMI; C-tick
RAID Management	MegaRAID Management Suite -MegaRAID Storage Manager -MegaCLI (command-line interface) -WebBIOS
OS Support	Extensive support includes Microsoft Windows Vista/2008/Server 2003/2000/XP, Linux, Solaris- (x86), Netware, FreeBSD, VMware and more. Visit the LSI download Center for the most complete list of supported operating systems: lsi.com/channel/support
